ZP-A63/3N 284909 Y7-284909 EATON ELECTRIC Off switch, 3pole+N, 63A
ZP-A63/3N
284909
Y7-284909
EATON-MOELLER
Off switch, 3pole+N, 63A
ZP-A63/3N
ZP-A63/3N. Off switch, 3pole+N, 63A
Off switch, type conforms to IEC/EN 60947-1, 1, -3, no. of poles: 1, 2, 3, 3N, amperages: 40 A, 63 A, accessories for protective switchgear for ZP-A can be used!
Devices for distribution board-/surface mounting > Main switch for distribution board
Modular Switchgear – Others and Accessories
Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER
Best sellers
▲More info
▲General specifications
Product specifications
| Feature Name | Feature Value |
|---|---|
| Switching function (EF000189) | Off switch |
| Number of contacts as normally open contact (EF008256) | 3 |
| Number of contacts as normally closed contact (EF008255) | 3 |
| Number of contacts as change-over contact (EF008257) | 0 |
| Number of poles (EF001391) | 4 |
| Rated current (EF000227) | 63 A |
| Rated voltage (EF000228) | 400 V |
| Min. rated voltage (EF005025) | 230 V |
| Rated switching capacity (EF002563) | 0 kA |
| Short-circuit breaking capacity (Icw) (EF002562) | 3 kA |
| Voltage type (EF000187) | AC |
| With signal lamp (EF000198) | No |
| Colour calotte (EF004668) | Other |
| Lamp type (EF002423) | Other |
| Lamp socket (EF004870) | Other |
| Max. lamp power (EF000260) | 0 W |
| Width in number of modular spacings (EF002950) | 4 |
| Built-in depth (EF000218) | 60 mm |
| Degree of protection (IP) (EF005474) | IP40 |
| Imprint/indication (EF003823) | Symbol "arrows" |
| Forced segregation according to DIN VDE 0113 (EFDE0032) | No |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF EATON XEFFECT SWITCHGEAR RANGE EN.pdf | 8 Mbytes |
|
| PDF CATALOGUE EATON EN .pdf | 38 Mbytes |
|
| ZP-A63/3N Y7-284909 284909 ES_248263.pdf | 256 Kbytes |
|
