> EATON - MOELLER>Bussmann fuses>CCP-1-100CF 1600136 ELECTRIC Lightning current / surge arresters, SPD insert, 600 VDC
Previous Product Next Product
CCP-1-100CF 1600136 EATON ELECTRIC Lightning current / surge arresters, SPD insert, 600 VDC View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

CCP-1-100CF 1600136 EATON ELECTRIC Lightning current / surge arresters, SPD insert, 600 VDC

CCP-1-100CF

CCP1100CF

1600136

EATON-MOELLER

6

Lightning current / surge arresters, SPD insert, 600 VDC

1 Pole Comp Ckt Protector 600Vdc 100A - Fused disconnector, low voltage, 100 A, AC 600 V, DC 125 V, CF, 1P, UL

1 Pole Comp Ckt Protector 600Vdc 100A

More details


Low-voltage industrial components > Fuse switch disconnector

Bussmann fuses

Brand new product in its original packaging covered by the warranties and certifications provided by EATON-MOELLER

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

Best sellers

▲

More info

▲


Fused disconnector, low voltage, 100 A, AC 600 V, DC 125 V, CF, 1P, UL
Control, Fused disconnector, low voltage, 100 A, AC 600 V, DC 125 V, CF, 1P, UL, 35 mm DIN-Rail mounting, Class CF fuse-link, UL 98, IP20, Breaking Capacity 200 kA

Technical data ETIM 7.0

Low-voltage industrial components (EG000017) / Fuse switch disconnector (EC001040)
Electric engineering, automation, process control engineering / Low-voltage switch technology / Off-load switch, circuit breaker, control switch / Fuse switch disconnector ([email protected] [AKF058013])
Version as main switch
No
Version as safety switch
No
Max. rated operation voltage Ue AC
600 V
Rated permanent current Iu
100 A
Rated operation power at AC-23, 400 V
kW
Conditioned rated short-circuit current Iq
200 kA
Rated short-time withstand current lcw
200 kA
Suitable for fuses
Other
Number of poles
1
With error protection
No
Type of electrical connection of main circuit
Screw connection
Cable entry
Other
Equipped with connectors
Yes
Suitable for ground mounting
No
Suitable for front mounting 4-hole
No
Suitable for busbar mounting
Yes
Type of control element
Rocker lever
Position control element
Front side
Motor drive optional
No
Motor drive integrated
No
Version as emergency stop installation
No
Degree of protection (IP), front side
IP20

Datasheet - PDF

▲
Title: Size: Type:
PDF EATON CIRCUIT PROTECTION BUSSMANN EN.pdf 23 Mbytes
PDF CATALOGUE EATON EN .pdf 38 Mbytes
CCP-1-100CF 1600136 CCP1100CF EN_CCP-1-100CF.pdf 103 Kbytes CCP-1-100CF 1600136 CCP1100CF EN_CCP-1-100CF.pdf
