104L4090 DANFOSS REFRIGERATION Tandem reciprocating compressor, SC18/18CL View larger
Images are for illustrative purposes only. Please refer to data sheet for details.

104L4090 DANFOSS REFRIGERATION Tandem reciprocating compressor, SC18/18CL

104L4090

DANFOSS REFRIGERATION

18

Tandem reciprocating compressor, SC18/18CL

Reciprocating compressor, SC18/18CL

More details


Home > DANFOSS REFRIGERATION

* Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

If our price is not the best, please ask us for a quote. Ask for a quotation

More info

▲


Refrigerants: R404A, Segment usage: Refrigeration LT, Compressor power supply [V]: 220-240/1/50

Product details

Gross weight30.056 Kg
Net weight29.1 Kg
Volume55.467 Liter
Gross weight30.056 Kg
Net weight29.1 Kg
Volume55.467 Liter

Auxiliary winding resistance (start winding) for single-phase compressors [Ohm]13.7
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm]13.7
Brand techniqueReciprocating compressor
Capacity controlFixed speed
ColourBlack
Compressor power supply [V]220-240/1/50
Configuration codeTandem
Cut in current HST [A]20.4 A
DescriptionSC18/18CL
Discharge connection angle [°]37 °
Discharge connection commentsRubber plug
Discharge connection diameter [mm]6.2 mm
Discharge connection height [mm]110 mm
Discharge connection materialCopper
EconomizerNo
FamilySC
Free gas volume [cm3]2920 cm³
Frequency [Hz]50
Height from baseplate [mm]254 mm
High value of nominal voltage at 50Hz [V]240 V
High value of voltage range at 50Hz [V]264 V
In scope of WEEE and contain batteriesNo
Length [mm]320 mm
Liquid injectionNo
Low value of nominal voltage at 50Hz [V]220 V
Low value of voltage range at 50Hz [V]198 V
LRA HST 60Hz [A]20.4 A
LRA HST [A]40.8 A
Main winding resistance for single-phase compressors [Ohm]3.7
Model numberSC18/18CL
Motor typeCSR
No. of phases (compressor)1
No. of phases (fan)1
Oil quantity [cm3]1220 cm³
Oil typePOE
Packing formatIndustrial pack
Phase1
Process connection angle [°]37 °
Process connection commentsRubber plug
Process connection diameter [mm]6.2 mm
Process connection height [mm]193 mm
Process connection materialCopper
Product groupHermetic compressors
Product Name DescriptionReciprocating compressor SC
Refrigerant charge [kg] [Max]2.2 kg
RLA3.90 A
Rotational speed at 50Hz [rpm]2900 rpm
Run capacitor capacitance10 µF
Start capacitor capacitance80 µF
Suction connection angle [°]37 °
Suction connection diameter [mm]16 mm
Suction connection height [mm]193 mm
Suction connection materialCopper
Swept volume [cm3]35.38 cm³
TechnologyReciprocating
Total height [mm]259 mm
TypeSC18/18
Voltage 50Hz [V]220 V
Voltage 50Hz [V] [Max]240 V
Width [mm]326 mm
Winding temperature short term [°C] [Max]135 °C
Winding temperature stat [°C] [Max]125 °C
Auxiliary winding resistance (start winding) for single-phase compressors [Ohm]13.7
Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm]13.7
Brand techniqueReciprocating compressor
Capacity controlFixed speed
ColourBlack
Compressor power supply [V]220-240/1/50
Configuration codeTandem
Cut in current HST [A]20.4 A
DescriptionSC18/18CL
Discharge connection angle [°]37 °
Discharge connection commentsRubber plug
Discharge connection diameter [mm]6.2 mm
Discharge connection height [mm]110 mm
Discharge connection materialCopper
EconomizerNo
FamilySC
Free gas volume [cm3]2920 cm³
Frequency [Hz]50
Height from baseplate [mm]254 mm
High value of nominal voltage at 50Hz [V]240 V
High value of voltage range at 50Hz [V]264 V
In scope of WEEE and contain batteriesNo
Length [mm]320 mm
Liquid injectionNo
Low value of nominal voltage at 50Hz [V]220 V
Low value of voltage range at 50Hz [V]198 V
LRA HST 60Hz [A]20.4 A
LRA HST [A]40.8 A
Main winding resistance for single-phase compressors [Ohm]3.7
Model numberSC18/18CL
Motor typeCSR
No. of phases (compressor)1
No. of phases (fan)1
Oil quantity [cm3]1220 cm³
Oil typePOE
Packing formatIndustrial pack
Phase1
Process connection angle [°]37 °
Process connection commentsRubber plug
Process connection diameter [mm]6.2 mm
Process connection height [mm]193 mm
Process connection materialCopper
Product groupHermetic compressors
Product Name DescriptionReciprocating compressor SC
Refrigerant charge [kg] [Max]2.2 kg
RLA3.90 A
Rotational speed at 50Hz [rpm]2900 rpm
Run capacitor capacitance10 µF
Start capacitor capacitance80 µF
Suction connection angle [°]37 °
Suction connection diameter [mm]16 mm
Suction connection height [mm]193 mm
Suction connection materialCopper
Swept volume [cm3]35.38 cm³
TechnologyReciprocating
Total height [mm]259 mm
TypeSC18/18
Voltage 50Hz [V]220 V
Voltage 50Hz [V] [Max]240 V
Width [mm]326 mm
Winding temperature short term [°C] [Max]135 °C
Winding temperature stat [°C] [Max]125 °C
