102G3255 DANFOSS REFRIGERATION Reciprocating compressor, TL2.5G
102G3255
DANFOSS REFRIGERATION
Reciprocating compressor, TL2.5G
Home > DANFOSS REFRIGERATION
* Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲Refrigerants: R134a, Use of segment: Refrigeration LT;Refrigeration MT
| Gross weight | 6.74 Kg |
| Net weight | 6.74 Kg |
| Oil | POE |
| Height total [mm] | 163 mm |
| Amps locked rotor LST [A] | 7 To |
| Applications | BPH LBP MBP |
| Approval standard | UL |
| Auxiliary winding resistance (start winding) for single-phase compressors [Ohm] | 4.9 Ohm |
| Auxiliary winding resistance (start winding) for single-phase compressors alt [Ohm] | 15 Ohm |
| Oil quantity [cm3] | 280 cm3 |
| Capacity control | Fixed speed |
| Refrigerant charge [kg] [Max] | 0.4 kg |
| Color | Black |
| Comments on the suction connection | Cover of The |
| Comments on the discharge connection | Cover of The |
| Comments on the process connection | Cover of The |
| Current connection HST, alternative [A] | 4.5 To |
| Current connection LST, alternative [A] | 7.5 To |
| Cut-in current LST [A] | 16 To |
| Configuration code | Individual |
| Description | TL2.5G |
| Description | TL |
| Designation | Compressor |
| Diameter of the suction connection [mm] | 6.5 mm |
| Diameter discharge connection [mm] | 5 mm |
| Economizer | Not |
| Packaging format | Industrial package |
| Frequency [Hz] | Sixty |
| Height from baseplate [mm] | 159 mm |
| LRA HST, alternative [A] | 4.5 To |
| LRA LST, alternative [A] | 2.8 To |
| Material of the discharge connection | Steel-plated Cu |
| Material of the process connection | Steel-plated Cu |
| N. º of phases (compressor) | One |
| N. º of phases (fan) | One |
| Energy level of the application | Compressor universal |
| Nominal cooling capacity of 60 kBTU/h | 0.95 KBtu/h |
| Nominal cooling capacity at 60Hz | 0.3 kW |
| Number of scheme | Eight thousand two hundred sixty three |
| Model number | TL2.5G |
| Oil charge [L] | 280 L |
| Phase | One |
| Process connection diameter [mm] | 6.5 mm |
| Refrigerants | R134a |
| Resistance of the primary winding for compressors in single-phase [Ohm] | 5.3 Ohm |
| Resistance of the primary winding for compressors in single-phase, alternative [ohm] | 31.5 Ohm |
| Swept volume [cm3] | 2.61 cm3 |
| Technology | Alternative |
| Temperature of the winding, the short-term [°C] [Max] | 135 °C |
| Winding temperature, stable [°C] [Max] | 125 °C |
| Voltage 60 Hz [V] [max.] | 115 V |
| Voltage, 60 Hz [V] | 115 V |
| Engine type | RSIR |
| Type of motherboard | EU, small |
| Technique of the brand | Compressor alternative |
| Units of packing | One hundred twenty five |
| Use of segment | Refrigeration LT Cooling MT |
| High value of nominal voltage at 50 Hz [V] | 0 V |
| High value of the nominal voltage at 60 Hz [V] | 115 V |
| High value of voltage range at 50hz [V] | 0 V |
| High value of the voltage range at 60 Hz [V] | 127 V |
| Low value of the rated voltage at 50 Hz [V] | 0 V |
| Low value of the nominal voltage at 60 Hz [V] | 115 V |
| Low value of voltage range at 50hz [V] | 0 V |
| Low value of the voltage range at 60 Hz [V] | 103 V |
| Rotation speed at 50 Hz [rpm] | 0 rpm |
| Rotation speed at 60 Hz [rpm] | 3500 rpm |
| Volume of free gas [cm3] | 1600 cm3 |
| Angle of the connection suction [°] | 30 ° |
| Angle of the discharge connection [°] | 28 ° |
| Angle of the connection process | 32 ° |
