DANFOSS REFRIGERATION 068U4583 068U4583 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

068U4583 DANFOSS REFRIGERATION Hot gas bypass regulator

Name: 068U4583 DANFOSS REFRIGERATION Hot gas bypass regulator
Brand: DANFOSS REFRIGERATION
SKU: DAO068U4583
Price: 199.86 USD
Availability: OutOfStock

Reference: 068U4583

Manufacturer: DANFOSS REFRIGERATION

Description:

Hot gas bypass regulator

TCHE/a Hot gas bypass reg

Hot gas bypass regulator, TCHE

Categories:

DANFOSS REFRIGERATION

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION

More Info
PDF
Reviews

Guarantee, repair and return.

Unit Price: 170,02 €

This price is per unit and is the net value (not including taxes if applicable).

Special discounts for registered customers.Login or register and prices will be updated.

Calculate price by quantity

Quantity	Price

Standard lead time: 4-5 days.

These delivery times are an estimate any may vary when the item order has been processed.
You will be notified of any change to delivery times once the order has been processed.
To this delivery time you have to add the time of transport from our logistics centre to your company.

LAST VIEWED

MORE INFO

Inlet connection type: Solder, ODF, Outlet connection type: Solder, ODF, Temperature range [°C]: -1 - 12, Orifice capacities [kW]: 3.4, Pressure equalization: Externally equalized

Product details

Gross weight	0.199 Kilogram
Net weight	0.178 Kilogram
Volume	0.489 Liter
EAN	5702428942003

Type	TCHE
Product group	Press. and temp. regul. valves
Product Name Description	Hot gas bypass regulator

Gross weight	0.199 Kilogram
Net weight	0.178 Kilogram
Volume	0.489 Liter
EAN	5702428942003
Type	TCHE
Product group	Press. and temp. regul. valves
Product Name Description	Hot gas bypass regulator

Approval	EAC LLC CDC TYSK
Body material	Stainless steel
Capillary tube length [in]	35 in
Capillary tube length [mm]	900 mm
China RoHS compliance	Yes with exemptions
Connection material	Bi-metal: Steel/copper
Contains batteries	No
Direction	Angleway
Equalization connection type	Solder, ODF
Equalization size [in]	1/4 in
EU RoHS compliance	Yes with exemptions
EU RoHS exemption clause	6(a) 6(c)
Flow direction	Single-flow
Flow direction indicator	Laser engraved 1-way arrow
Fluid Group	2
Identical product	068U4537
Inlet connection type	Solder, ODF
Inlet size [in]	3/8 in
Max. Working Pressure [bar]	45.5 bar
Max. Working Pressure [psig]	660 psig
Orifice capacities [kW]	3.4 kW
Orifice capacities [TR]	1 TR
Orifice size	4

Outlet connection type	Solder, ODF
Outlet size [in]	1/2 in
Packing format	Multi pack
Parts included	Bulb strap
PED category	Art. 4, par. 3
Pressure equalization	Externally equalized
Product accessories	TXV accessories
Quantity per packing format	20 pc
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
Refrigerants	R134a/R513A
SCIP dossier no.	07795324-de66-41b2-9761-afe6640e393c
SCIP dossier product name	TU/TC - Thermostatic expansion valve
Seal	No
Serviceable	No
Static Superheat (SS) [°C]	2 °C
Static Superheat (SS) [°F]	3.6 °F
Superheat setting	Adjustable
Temperature range [°C] [max]	12 °C
Temperature range [°C] [min]	-1 °C
Temperature range [°F] [max]	54 °F
Temperature range [°F] [min]	30 °F
UA address	UA_2L.png

Approval	EAC LLC CDC TYSK
Body material	Stainless steel
Capillary tube length [in]	35 in
Capillary tube length [mm]	900 mm
China RoHS compliance	Yes with exemptions
Connection material	Bi-metal: Steel/copper
Contains batteries	No
Direction	Angleway
Equalization connection type	Solder, ODF
Equalization size [in]	1/4 in
EU RoHS compliance	Yes with exemptions
EU RoHS exemption clause	6(a) 6(c)
Flow direction	Single-flow
Flow direction indicator	Laser engraved 1-way arrow
Fluid Group	2
Identical product	068U4537
Inlet connection type	Solder, ODF
Inlet size [in]	3/8 in
Max. Working Pressure [bar]	45.5 bar
Max. Working Pressure [psig]	660 psig
Orifice capacities [kW]	3.4 kW
Orifice capacities [TR]	1 TR
Orifice size	4
Outlet connection type	Solder, ODF
Outlet size [in]	1/2 in
Packing format	Multi pack
Parts included	Bulb strap
PED category	Art. 4, par. 3
Pressure equalization	Externally equalized
Product accessories	TXV accessories
Quantity per packing format	20 pc
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
Refrigerants	R134a/R513A
SCIP dossier no.	07795324-de66-41b2-9761-afe6640e393c
SCIP dossier product name	TU/TC - Thermostatic expansion valve
Seal	No
Serviceable	No
Static Superheat (SS) [°C]	2 °C
Static Superheat (SS) [°F]	3.6 °F
Superheat setting	Adjustable
Temperature range [°C] [max]	12 °C
Temperature range [°C] [min]	-1 °C
Temperature range [°F] [max]	54 °F
Temperature range [°F] [min]	30 °F
UA address	UA_2L.png
