DANFOSS REFRIGERATION061N3000 DANFOSS REFRIGERATION Check valve, BCV
DANFOSS REFRIGERATION 061N3000 061N3000 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

061N3000 DANFOSS REFRIGERATION Check valve, BCV

Reference: 061N3000

Manufacturer: DANFOSS REFRIGERATION

Description:

Check valve, BCV
Check valve, BCV, Max. Working Pressure [bar]: 41.5

Categories:

  • DANFOSS REFRIGERATION

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

Total: 4.768,25 €

Unit Price: 19,073 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 4-5 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Inlet connection type: Solder, ODF, Outlet connection type: Solder, ODF, Direction: Straightway, Packing format: Industrial pack

Product details

Gross weight0.042 Kilogram
Net weight0.041 Kilogram
Volume0.031 Liter
EAN5702428269346
TypeBCV
Product groupCheck valves
Product Name DescriptionCheck valve
Gross weight0.042 Kilogram
Net weight0.041 Kilogram
Volume0.031 Liter
EAN5702428269346
TypeBCV
Product groupCheck valves
Product Name DescriptionCheck valve

ApprovalCE
Body materialCopper
CE markYes
Connection materialCopper
Contains batteriesNo
Cv value [gal/min]0.97 gal/min
DesignFloat
DirectionStraightway
Flow directionSingle-flow
Flow direction indicatorLabel printed 1-way arrow
Inlet connection typeSolder, ODF
Inlet size [in]3/8 in
Kv value [m³/h]0.83 m³/h
Max. Working Pressure [bar]41.5 bar
Max. Working Pressure [psig]602 psig
Min. Pressure drop [bar]0.078 bar
Min. Pressure drop [psi]1.1 psi
Outlet connection typeSolder, ODF
Outlet size [in]3/8 in
Packing formatIndustrial pack
Quantity per packing format250 pc
REACH Candidate List substancesLead (CAS no. 7439-92-1)
RefrigerantsR134a
R404A
R407C
R410A
R507A
R22/R407C
SCIP dossier no.be7ba087-4bcb-4c85-8e38-190a736d6307
SCIP dossier product nameCheck valve(3)
Temperature range [°C] [max]120 °C
Temperature range [°C] [min]-30 °C
Temperature range [°F] [max]248 °F
Temperature range [°F] [min]-22 °F
Type designationBCV-603DY
ApprovalCE
Body materialCopper
CE markYes
Connection materialCopper
Contains batteriesNo
Cv value [gal/min]0.97 gal/min
DesignFloat
DirectionStraightway
Flow directionSingle-flow
Flow direction indicatorLabel printed 1-way arrow
Inlet connection typeSolder, ODF
Inlet size [in]3/8 in
Kv value [m³/h]0.83 m³/h
Max. Working Pressure [bar]41.5 bar
Max. Working Pressure [psig]602 psig
Min. Pressure drop [bar]0.078 bar
Min. Pressure drop [psi]1.1 psi
Outlet connection typeSolder, ODF
Outlet size [in]3/8 in
Packing formatIndustrial pack
Quantity per packing format250 pc
REACH Candidate List substancesLead (CAS no. 7439-92-1)
RefrigerantsR134a
R404A
R407C
R410A
R507A
R22/R407C
SCIP dossier no.be7ba087-4bcb-4c85-8e38-190a736d6307
SCIP dossier product nameCheck valve(3)
Temperature range [°C] [max]120 °C
Temperature range [°C] [min]-30 °C
Temperature range [°F] [max]248 °F
Temperature range [°F] [min]-22 °F
Type designationBCV-603DY
