042N7696 DANFOSS REFRIGERATION Solenoid coil, AU012DS
042N7696
DANFOSS REFRIGERATION
Solenoid coil, AU012DS
Coil AU012DS 12V DC 1m Cable
Solenoid coil, AU012DS, Cable, 1 m, Supply voltage [V] DC: 12, Multi pack
Home > DANFOSS REFRIGERATION
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲Electrical connection: Cable, Supply voltage [V] DC: 12, Enclosure rating IP: IP67, Actuator size: 9 mm
Product details
| Gross weight | 0.228 Kilogram |
| Net weight | 0.169 Kilogram |
| Volume | 0.904 Liter |
| EAN | 5702428053938 |
| Type | AU012DS |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Gross weight | 0.228 Kilogram |
| Net weight | 0.169 Kilogram |
| Volume | 0.904 Liter |
| EAN | 5702428053938 |
| Type | AU012DS |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Actuator size | 9 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 122 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | LLC CDC TYSK |
| Cable length [in] | 40 in |
| Cable length [m] | 1 m |
| China RoHS compliance | Yes |
| China RoHS exemption clause | No |
| Coil connection | Cable |
| Coil fastening | Clip-on |
| Colour | Blue |
| Compliance | EN 60730-1 |
| Conductor area [mm2] | 3 x 0.75 mm2 |
| Contains batteries | No |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical connection | Cable |
| Electrical connector | 3 core cable |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Identical product | 042N8696 |
| In scope of WEEE | Yes |
| Packing format | Multi pack |
| Parts Program name | EV220S |
| Power consumption [W] DC | 12 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Rel. Humidity [% RH] [max] | 100 % |
| Rel. Humidity [% RH] [min] | 0 % |
| Serviceable | No |
| Spare part number | 042N7696 |
| Supply voltage [V] DC | 12 V |
| Type designation | AU012DS |
| Actuator size | 9 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 122 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | LLC CDC TYSK |
| Cable length [in] | 40 in |
| Cable length [m] | 1 m |
| China RoHS compliance | Yes |
| China RoHS exemption clause | No |
| Coil connection | Cable |
| Coil fastening | Clip-on |
| Colour | Blue |
| Compliance | EN 60730-1 |
| Conductor area [mm2] | 3 x 0.75 mm2 |
| Contains batteries | No |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical connection | Cable |
| Electrical connector | 3 core cable |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Identical product | 042N8696 |
| In scope of WEEE | Yes |
| Packing format | Multi pack |
| Parts Program name | EV220S |
| Power consumption [W] DC | 12 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Rel. Humidity [% RH] [max] | 100 % |
| Rel. Humidity [% RH] [min] | 0 % |
| Serviceable | No |
| Spare part number | 042N7696 |
| Supply voltage [V] DC | 12 V |
| Type designation | AU012DS |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS REFRIGERATION AND AIRCONDITIONING EN.pdf | 11 Mbytes |
|
| 042N7696 042N7696 IT_042N4230.pdf | 1 Mbytes |
|
