042N4233 DANFOSS REFRIGERATION Solenoid coil, AY120C
042N4233
DANFOSS REFRIGERATION
Solenoid coil, AY120C
Coil AY120C 110-120V 50/60Hz Ext. Frame
Solenoid coil, AY120C, US Spade, Supply voltage [V] AC: 110 - 120, Multi pack
Home > DANFOSS REFRIGERATION
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲Electrical connection: US Spade, Supply voltage [V] AC: 110 - 120, Frequency [Hz]: 50/60 Hz, Enclosure rating IP: IP00
Product details
| Gross weight | 0.106 Kilogram |
| Net weight | 0.096 Kilogram |
| Volume | 0.098 Liter |
| EAN | 5702423272426 |
| Type | AY120C |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Gross weight | 0.106 Kilogram |
| Net weight | 0.096 Kilogram |
| Volume | 0.098 Liter |
| EAN | 5702423272426 |
| Type | AY120C |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Actuator size | 9 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | LLC CDC TYSK cURus |
| China RoHS compliance | Out of scope |
| China RoHS exemption clause | No |
| Coil connection | US 0.25 in Spade |
| Coil fastening | Clip-on |
| Colour | Blue |
| Compliance | UL 429 |
| Contains batteries | No |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical connection | US Spade |
| Electrical connection size | 0.25 in |
| Electrical connector | 2 x spades |
| Enclosure rating IP | IP00 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Frequency [Hz] | 50/60 Hz |
| Identical product | 042N8233 |
| In scope of WEEE | Yes |
| Packing format | Multi pack |
| Parts Program name | EV220S |
| Power consumption 50Hz [VA] | 16 VA |
| Power consumption 60Hz [VA] | 16 VA |
| Power consumption [W] 50Hz | 8 W |
| Power consumption [W] 60Hz | 8 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Serviceable | No |
| Spare part number | 042N4233 |
| Supply voltage 50Hz Max [V] | 120 V |
| Supply voltage 50Hz Min [V] | 110 V |
| Supply voltage 60Hz Max [V] | 120 V |
| Supply voltage 60Hz Min [V] | 110 V |
| Supply voltage [V] AC [max] | 120 V |
| Supply voltage [V] AC [min] | 110 V |
| Type designation | AY120C |
| UL approval file name | MH29671 |
| UL mark | Yes |
| Actuator size | 9 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | LLC CDC TYSK cURus |
| China RoHS compliance | Out of scope |
| China RoHS exemption clause | No |
| Coil connection | US 0.25 in Spade |
| Coil fastening | Clip-on |
| Colour | Blue |
| Compliance | UL 429 |
| Contains batteries | No |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Electrical connection | US Spade |
| Electrical connection size | 0.25 in |
| Electrical connector | 2 x spades |
| Enclosure rating IP | IP00 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Frequency [Hz] | 50/60 Hz |
| Identical product | 042N8233 |
| In scope of WEEE | Yes |
| Packing format | Multi pack |
| Parts Program name | EV220S |
| Power consumption 50Hz [VA] | 16 VA |
| Power consumption 60Hz [VA] | 16 VA |
| Power consumption [W] 50Hz | 8 W |
| Power consumption [W] 60Hz | 8 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 24 pc |
| REACH Candidate List substances | No |
| Serviceable | No |
| Spare part number | 042N4233 |
| Supply voltage 50Hz Max [V] | 120 V |
| Supply voltage 50Hz Min [V] | 110 V |
| Supply voltage 60Hz Max [V] | 120 V |
| Supply voltage 60Hz Min [V] | 110 V |
| Supply voltage [V] AC [max] | 120 V |
| Supply voltage [V] AC [min] | 110 V |
| Type designation | AY120C |
| UL approval file name | MH29671 |
| UL mark | Yes |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS REFRIGERATION AND AIRCONDITIONING EN.pdf | 11 Mbytes |
|
| 042N4233 042N4233 IT_042N4230.pdf | 1 Mbytes |
|
