034G7900 DANFOSS REFRIGERATION Electric expansion valve
034G7900
DANFOSS REFRIGERATION
Electric expansion valve
ETS 24C Electric exp. valve 1/2x1/2
Electric expansion valve, ETS 24C
Home > DANFOSS REFRIGERATION
* Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
More info
▲Inlet connection type: Solder ODF, Outlet size [in]: 1/2 in
Product details
| Gross weight | 0.399 Kg |
| Net weight | 0.304 Kg |
| Volume | 1.607 Liter |
| EAN | 5702428908580 |
| Gross weight | 0.399 Kg |
| Net weight | 0.304 Kg |
| Volume | 1.607 Liter |
| EAN | 5702428908580 |
| Ambient temperature range [°C] [max] | 70 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 158 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | CE EAC LLC CDC TYSK UR ATEX CCC CMIM UKCA |
| Balanced port [Yes/No] | Yes |
| Body material | Stainless steel |
| Brand | Colibri |
| Compatible Danfoss controllers | EKE 1A EKE 1B EKE 1C MCX 152V MCX 061V |
| Connection material | Bi-metal: Steel/copper |
| Direction | Straightway |
| Electrical conn. Male/Female | Male |
| Electrical connection | M12 |
| Electrical connection size | 4 pin |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Yes with exemptions |
| EX Sales text | -40 / +70C II 3G Ex ec IIB T4 Gc |
| Flow direction | Bi-flow |
| Flow direction indicator | Laser engraved 2-way arrow |
| Fluid Group | 1 |
| Full travel time speed [s] [max] | 6 s |
| Full travel time speed [s] [min] | 3 s |
| In scope of WEEE and contain batteries | No |
| Inlet connection type | Solder ODF |
| Inlet size [in] | 1/2 in |
| Kv value [m³/h] | 1.3 m³/h |
| Lubricants compatibility | MO POE |
| Manual operation option | AST-G service driver |
| Max allowed duty cycle [%] | 100 % |
| Max tot PowerCons CurrDrive[W] | 7.2 W |
| Max tot PowerCons VoltDrive[W] | 7.2 W |
| Max. Working Pressure [bar] | 50 bar |
| Max. Working Pressure [psig] | 725 psig |
| MaxOPD [bar] | 40 bar |
| MaxOPD [psi] | 580 psi |
| MaxOPD reverse [bar] | 40 bar |
| MaxOPD reverse [psi] | 580 psi |
| Motor type | Bi-polar |
| Oil free refrigerants | R1234ze(E) R134a R513A R515A R515B R516A |
| Operating current max. [A] | 0.8 A |
| Outlet connection type | Solder ODF |
| Outlet size [in] | 1/2 in |
| Packing format | Multi pack |
| PED category | Art. 4, par. 3 |
| Phase current (peak) [mA] | 800 mA |
| Phase current (RMS) [mA] | 600 mA |
| Phase inductance [µH] | 14000 μH |
| Product accessories | Stepper valve accessories |
| Product group | Expansion valves |
| Product Name Description | Electric expansion valve |
| Quantity per packing format | 12 pc |
| Rated cap. cond. note | Full stroke open, normal flow |
| Rated cap. conditions [IMP] | tcond=90 ºF tevap=40 ºF tliq=82 ºF |
| Rated cap. conditions [SI] | tcond=32 ºC tevap=5 ºC tliq=28 ºC |
| Rated cap. R404A/R507A [kW] | 80 kW |
| Rated cap. R404A/R507A [TR] | 37.3 TR |
| Rated capacity R134a [kW] | 83.9 kW |
| Rated capacity R134a [TR] | 24.2 TR |
| Rated capacity R22 [kW] | 141 kW |
| Rated capacity R22 [TR] | 40.1 TR |
| Rated capacity R407C [kW] | 117 kW |
| Rated capacity R407C [TR] | 33.7 TR |
| Rated capacity R410A [kW] | 129 kW |
| Rated capacity R410A [TR] | 37.3 TR |
| Refrigerant temperature [ºC] [max] | 70 °C |
| Refrigerant temperature [ºC] [min] | -40 °C |
| Refrigerant temperature [ºF] [max] | 158 °F |
| Refrigerant temperature [ºF] [min] | -40 °F |
| Refrigerants | R1234yf R1270 R134a R23 R290 R32 R404A R407A R407C R407F R410A R417A R422A R422D R427A R438A R444B R448A R449A R450A R452A R452B R454B R513A R600 R600a R1233zd(E) R22 R407B R407H R413A R422B R442A R447A R449B R454A R454C R455A R463A R502 R512A R513B R515A R515B R516A R245fa R412A R1234ze(E) R227ea R507A |
| Resistance [kOhm] | 0 kOhm |
| Serviceable | No |
| Sightglass | No |
| Step mode | 2-phase full step Half step Microstep (recommended) |
| Total steps | 600 (full steps) |
| Type | ETS 24C |
| UL approved refrigerants | R134a R227ea R23 R404A R407A R407C R407F R410A R417A R422A R422D R427A R438A R448A R449A R450A R452A R507A R513A |
| Ambient temperature range [°C] [max] | 70 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 158 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | CE EAC LLC CDC TYSK UR ATEX CCC CMIM UKCA |
| Balanced port [Yes/No] | Yes |
| Body material | Stainless steel |
| Brand | Colibri |
| Compatible Danfoss controllers | EKE 1A EKE 1B EKE 1C MCX 152V MCX 061V |
| Connection material | Bi-metal: Steel/copper |
| Direction | Straightway |
| Electrical conn. Male/Female | Male |
| Electrical connection | M12 |
| Electrical connection size | 4 pin |
| Enclosure rating IP | IP67 |
| EU RoHS compliance | Yes with exemptions |
| EX Sales text | -40 / +70C II 3G Ex ec IIB T4 Gc |
| Flow direction | Bi-flow |
| Flow direction indicator | Laser engraved 2-way arrow |
| Fluid Group | 1 |
| Full travel time speed [s] [max] | 6 s |
| Full travel time speed [s] [min] | 3 s |
| In scope of WEEE and contain batteries | No |
| Inlet connection type | Solder ODF |
| Inlet size [in] | 1/2 in |
| Kv value [m³/h] | 1.3 m³/h |
| Lubricants compatibility | MO POE |
| Manual operation option | AST-G service driver |
| Max allowed duty cycle [%] | 100 % |
| Max tot PowerCons CurrDrive[W] | 7.2 W |
| Max tot PowerCons VoltDrive[W] | 7.2 W |
| Max. Working Pressure [bar] | 50 bar |
| Max. Working Pressure [psig] | 725 psig |
| MaxOPD [bar] | 40 bar |
| MaxOPD [psi] | 580 psi |
| MaxOPD reverse [bar] | 40 bar |
| MaxOPD reverse [psi] | 580 psi |
| Motor type | Bi-polar |
| Oil free refrigerants | R1234ze(E) R134a R513A R515A R515B R516A |
| Operating current max. [A] | 0.8 A |
| Outlet connection type | Solder ODF |
| Outlet size [in] | 1/2 in |
| Packing format | Multi pack |
| PED category | Art. 4, par. 3 |
| Phase current (peak) [mA] | 800 mA |
| Phase current (RMS) [mA] | 600 mA |
| Phase inductance [µH] | 14000 μH |
| Product accessories | Stepper valve accessories |
| Product group | Expansion valves |
| Product Name Description | Electric expansion valve |
| Quantity per packing format | 12 pc |
| Rated cap. cond. note | Full stroke open, normal flow |
| Rated cap. conditions [IMP] | tcond=90 ºF tevap=40 ºF tliq=82 ºF |
| Rated cap. conditions [SI] | tcond=32 ºC tevap=5 ºC tliq=28 ºC |
| Rated cap. R404A/R507A [kW] | 80 kW |
| Rated cap. R404A/R507A [TR] | 37.3 TR |
| Rated capacity R134a [kW] | 83.9 kW |
| Rated capacity R134a [TR] | 24.2 TR |
| Rated capacity R22 [kW] | 141 kW |
| Rated capacity R22 [TR] | 40.1 TR |
| Rated capacity R407C [kW] | 117 kW |
| Rated capacity R407C [TR] | 33.7 TR |
| Rated capacity R410A [kW] | 129 kW |
| Rated capacity R410A [TR] | 37.3 TR |
| Refrigerant temperature [ºC] [max] | 70 °C |
| Refrigerant temperature [ºC] [min] | -40 °C |
| Refrigerant temperature [ºF] [max] | 158 °F |
| Refrigerant temperature [ºF] [min] | -40 °F |
| Refrigerants | R1234yf R1270 R134a R23 R290 R32 R404A R407A R407C R407F R410A R417A R422A R422D R427A R438A R444B R448A R449A R450A R452A R452B R454B R513A R600 R600a R1233zd(E) R22 R407B R407H R413A R422B R442A R447A R449B R454A R454C R455A R463A R502 R512A R513B R515A R515B R516A R245fa R412A R1234ze(E) R227ea R507A |
| Resistance [kOhm] | 0 kOhm |
| Serviceable | No |
| Sightglass | No |
| Step mode | 2-phase full step Half step Microstep (recommended) |
| Total steps | 600 (full steps) |
| Type | ETS 24C |
| UL approved refrigerants | R134a R227ea R23 R404A R407A R407C R407F R410A R417A R422A R422D R427A R438A R448A R449A R450A R452A R507A R513A |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| 034G7900 034G7900 ES_034G7500.pdf | 2 Mbytes |
 |
