027H7274 DANFOSS REFRIGERATION CCMT 5L valve ODF-ODF 7/8
027H7274
DANFOSS REFRIGERATION
CCMT 5L valve ODF-ODF 7/8
Electric regulating valve, CCMT 5L, 7/8 in
Home > DANFOSS REFRIGERATION
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲Refrigerants: R744, Kv value [m³/h]: 0.48, Max. Working Pressure [bar]: 140, Connection type: Solder, ODF, Connection Weld size [in]: 3/4 in, Packing format: Multi pack, Quantity per packing format: 9
Product details
| Gross weight | 0.809 Kilogram |
| Net weight | 0.672 Kilogram |
| Volume | 2.236 Liter |
| EAN | 5702424053659 |
| Type | CCMT 5L |
| Product group | Press. and temp. regul. valves |
| Product Name Description | Electric regulating valve |
| Gross weight | 0.809 Kilogram |
| Net weight | 0.672 Kilogram |
| Volume | 2.236 Liter |
| EAN | 5702424053659 |
| Type | CCMT 5L |
| Product group | Press. and temp. regul. valves |
| Product Name Description | Electric regulating valve |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| China RoHS compliance | Yes |
| China RoHS exemption clause | No |
| Connection Solder size [in] | 7/8 in |
| Connection standard | EN10220 |
| Connection type | Solder, ODF |
| Connection Weld size [in] | 3/4 in |
| Contains batteries | No |
| Cv value [gal/min] | 0.555 gal/min |
| Diff.press.setting range [bar] | 90 bar |
| Diff.press.setting range [psi] | 1305 psi |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Kv value [m³/h] | 0.48 m³/h |
| Max. Working Pressure [bar] | 140 bar |
| Max. Working Pressure [psig] | 2030 psig |
| MaxOPD [bar] | 90 bar |
| MaxOPD [psig] | 1305 psig |
| Packing format | Multi pack |
| Product accessories | Electric valve accessories |
| Product description | Electric Expansion Valve |
| Quantity per packing format | 9 pc |
| REACH Candidate List substances | No |
| Refrigerants | R744 |
| Serviceable | Electric valve spare parts |
| Temperature range [°C] [max] | 55 °C |
| Temperature range [°C] [min] | -20 °C |
| Temperature range [°F] [max] | 131 °F |
| Temperature range [°F] [min] | -4 °F |
| UL approved refrigerants | R744 |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| China RoHS compliance | Yes |
| China RoHS exemption clause | No |
| Connection Solder size [in] | 7/8 in |
| Connection standard | EN10220 |
| Connection type | Solder, ODF |
| Connection Weld size [in] | 3/4 in |
| Contains batteries | No |
| Cv value [gal/min] | 0.555 gal/min |
| Diff.press.setting range [bar] | 90 bar |
| Diff.press.setting range [psi] | 1305 psi |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Kv value [m³/h] | 0.48 m³/h |
| Max. Working Pressure [bar] | 140 bar |
| Max. Working Pressure [psig] | 2030 psig |
| MaxOPD [bar] | 90 bar |
| MaxOPD [psig] | 1305 psig |
| Packing format | Multi pack |
| Product accessories | Electric valve accessories |
| Product description | Electric Expansion Valve |
| Quantity per packing format | 9 pc |
| REACH Candidate List substances | No |
| Refrigerants | R744 |
| Serviceable | Electric valve spare parts |
| Temperature range [°C] [max] | 55 °C |
| Temperature range [°C] [min] | -20 °C |
| Temperature range [°F] [max] | 131 °F |
| Temperature range [°F] [min] | -4 °F |
| UL approved refrigerants | R744 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS REFRIGERATION AND AIRCONDITIONING EN.pdf | 11 Mbytes |
|
| 027H7274 027H7274 FR_027H7243.pdf | 2 Mbytes |
|
