023Z8512 DANFOSS REFRIGERATION Hermetic filter drier

Name: 023Z8512 DANFOSS REFRIGERATION Hermetic filter drier
Brand: DANFOSS REFRIGERATION
SKU: DAO023Z8512
Price: 43.25 USD
Availability: OutOfStock

Reference: 023Z8512

Manufacturer: DANFOSS REFRIGERATION

Description:

Hermetic filter drier

Filter drier DMSC 032S M/24

Hermetic filter drier, DMSC, 03 cu.in., Copper

Categories:

DANFOSS REFRIGERATION

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION

More Info
PDF
Reviews

Guarantee, repair and return.

Unit Price: 38,64 €

This price is per unit and is the net value (not including taxes if applicable).

Special discounts for registered customers.Login or register and prices will be updated.

Calculate price by quantity

Quantity	Price

Standard lead time: 4-5 days.

These delivery times are an estimate any may vary when the item order has been processed.
You will be notified of any change to delivery times once the order has been processed.
To this delivery time you have to add the time of transport from our logistics centre to your company.

LAST VIEWED

MORE INFO

Inlet connection type: Solder, ODF, Outlet connection type: Solder, ODF, Core Size code: 03 cu.in., Packing format: Multi pack, Quantity per packing format: 24

Product details

Gross weight	0.424 Kilogram
Net weight	0.39 Kilogram
Volume	0.555 Liter
EAN	5702428513098

Type	DMSC
Product group	Filter driers
Product Name Description	Hermetic filter drier

Gross weight	0.424 Kilogram
Net weight	0.39 Kilogram
Volume	0.555 Liter
EAN	5702428513098
Type	DMSC
Product group	Filter driers
Product Name Description	Hermetic filter drier

Activated alumina [%]	0 %
Body material	Steel
Braket	No
Brand	ELIMINATOR
China RoHS compliance	Yes
China RoHS exemption clause	No
Connection material	Copper
Contains batteries	No
Core	Solid core
Core Size code	03 cu.in.
Core type	Solid core
EU RoHS compliance	Yes
EU RoHS exemption clause	No
Filter application	High Moisture Capacity
Flow direction indicator	Label printed 1-way arrow
Fluid Group	2
Inlet 1 connection size [in]	1/4 in
Inlet connection type	Solder, ODF
Max. Working Pressure [bar]	52 bar
Max. Working Pressure [psig]	754 psig
Molecular sieve [%]	100 %
Net volume [foz US]	2.84 Fluid Ounce US
Net volume [l]	0.084 L

Outlet 1 connection size [in]	1/4 in
Outlet connection type	Solder, ODF
Packing format	Multi pack
PED category	Art. 4, par. 3
Product description	Liquid line filter drier
Quantity per packing format	24 pc
REACH Candidate List substances	No
Refrigerants	R744
Serviceable	No
Shell volume [foz US]	4 Fluid Ounce US
Shell volume [l]	0.12 L
Solid core surface [cm2]	72 cm²
Solid core surface [in2]	11.16 in²
Solid core volume [cm3]	55 cm³
Solid core volume [in3]	3.35 in³
Temperature range [°C] [max]	17 °C
Temperature range [°C] [min]	-30 °C
Temperature range [°F] [max]	63 °F
Temperature range [°F] [min]	-22 °F
Type designation	DMSC 032S
UL approval file name	SA6398
UL approved refrigerants	R744
UL mark	Yes

Activated alumina [%]	0 %
Body material	Steel
Braket	No
Brand	ELIMINATOR
China RoHS compliance	Yes
China RoHS exemption clause	No
Connection material	Copper
Contains batteries	No
Core	Solid core
Core Size code	03 cu.in.
Core type	Solid core
EU RoHS compliance	Yes
EU RoHS exemption clause	No
Filter application	High Moisture Capacity
Flow direction indicator	Label printed 1-way arrow
Fluid Group	2
Inlet 1 connection size [in]	1/4 in
Inlet connection type	Solder, ODF
Max. Working Pressure [bar]	52 bar
Max. Working Pressure [psig]	754 psig
Molecular sieve [%]	100 %
Net volume [foz US]	2.84 Fluid Ounce US
Net volume [l]	0.084 L
Outlet 1 connection size [in]	1/4 in
Outlet connection type	Solder, ODF
Packing format	Multi pack
PED category	Art. 4, par. 3
Product description	Liquid line filter drier
Quantity per packing format	24 pc
REACH Candidate List substances	No
Refrigerants	R744
Serviceable	No
Shell volume [foz US]	4 Fluid Ounce US
Shell volume [l]	0.12 L
Solid core surface [cm2]	72 cm²
Solid core surface [in2]	11.16 in²
Solid core volume [cm3]	55 cm³
Solid core volume [in3]	3.35 in³
Temperature range [°C] [max]	17 °C
Temperature range [°C] [min]	-30 °C
Temperature range [°F] [max]	63 °F
Temperature range [°F] [min]	-22 °F
Type designation	DMSC 032S
UL approval file name	SA6398
UL approved refrigerants	R744
UL mark	Yes
