018F4134 DANFOSS REFRIGERATION Solenoid coil
018F4134
DANFOSS REFRIGERATION
Solenoid coil
Coil BJ240BS 240V 60Hz Junction Box
Solenoid coil, BJ240BS, Junction Box, 0.2 m, Supply voltage [V] AC: 240, Multi pack
Home > DANFOSS REFRIGERATION
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS REFRIGERATION
Best sellers
▲More info
▲Electrical connection: Junction Box, Supply voltage [V] AC: 240, Frequency [Hz]: 60 Hz, Enclosure rating IP: IP30
Product details
| Gross weight | 0.392 Kilogram |
| Net weight | 0.39 Kilogram |
| Volume | 0.295 Liter |
| EAN | 5702428890724 |
| Type | BJ240BS |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Gross weight | 0.392 Kilogram |
| Net weight | 0.39 Kilogram |
| Volume | 0.295 Liter |
| EAN | 5702428890724 |
| Type | BJ240BS |
| Product group | Solenoid valves |
| Product Name Description | Solenoid coil |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | C UL US LISTED LLC CDC TYSK |
| Cable length [in] | 8 in |
| Cable length [m] | 0.2 m |
| China RoHS compliance | Yes |
| China RoHS exemption clause | No |
| Coil connection | Junction Box |
| Coil design standard | UL 429 |
| Coil fastening | Clip-on |
| Coil winding insulation class | Class H to IEC 85 |
| Colour | Black |
| Compliance | UL 429 |
| Contains batteries | No |
| Electrical conn. comments | Flying leads |
| Electrical connection | Junction Box |
| Electrical connection standard | UL50E CLASS 2 |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 2 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Frame design | Ext. metal frame |
| Frequency [Hz] | 60 Hz |
| Packing format | Multi pack |
| Parts Program name | EV210B EV215B EV220B 15 - 50 EV220B 6 - 22 EV225B EV245B EV250B |
| Pollution degree | 3 |
| Power consumption [W] 60Hz | 16 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 35 pc |
| REACH Candidate List substances | No |
| Rel. Humidity [% RH] [max] | 97 % |
| Rel. Humidity [% RH] [min] | 0 % |
| Rel. Humidity conditions | Non-condensation |
| Serviceable | No |
| Spare part number | 018F4134 |
| Supply voltage 60Hz Max [V] | 240 V |
| Supply voltage [V] AC | 240 V |
| Type designation | BJ240BS |
| UL approval file name | MH29671 |
| UL mark | Yes |
| Actuator size | 13.5 mm |
| Ambient temperature range [°C] [max] | 50 °C |
| Ambient temperature range [°C] [min] | -40 °C |
| Ambient temperature range [°F] [max] | 120 °F |
| Ambient temperature range [°F] [min] | -40 °F |
| Approval | C UL US LISTED LLC CDC TYSK |
| Cable length [in] | 8 in |
| Cable length [m] | 0.2 m |
| China RoHS compliance | Yes |
| China RoHS exemption clause | No |
| Coil connection | Junction Box |
| Coil design standard | UL 429 |
| Coil fastening | Clip-on |
| Coil winding insulation class | Class H to IEC 85 |
| Colour | Black |
| Compliance | UL 429 |
| Contains batteries | No |
| Electrical conn. comments | Flying leads |
| Electrical connection | Junction Box |
| Electrical connection standard | UL50E CLASS 2 |
| Enclosure rating IP | IP30 |
| Enclosure rating Nema (~) | 2 |
| EU RoHS compliance | Yes |
| EU RoHS exemption clause | No |
| Frame design | Ext. metal frame |
| Frequency [Hz] | 60 Hz |
| Packing format | Multi pack |
| Parts Program name | EV210B EV215B EV220B 15 - 50 EV220B 6 - 22 EV225B EV245B EV250B |
| Pollution degree | 3 |
| Power consumption [W] 60Hz | 16 W |
| Product accessories | Solenoid coil accessories |
| Quantity per packing format | 35 pc |
| REACH Candidate List substances | No |
| Rel. Humidity [% RH] [max] | 97 % |
| Rel. Humidity [% RH] [min] | 0 % |
| Rel. Humidity conditions | Non-condensation |
| Serviceable | No |
| Spare part number | 018F4134 |
| Supply voltage 60Hz Max [V] | 240 V |
| Supply voltage [V] AC | 240 V |
| Type designation | BJ240BS |
| UL approval file name | MH29671 |
| UL mark | Yes |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS REFRIGERATION AND AIRCONDITIONING EN.pdf | 11 Mbytes |
|
| 018F4134 018F4134 ES_018F4100.pdf | 470 Kbytes |
|
