082H0276 DANFOSS HEATING AMB 182 15Nm 2-point 60s 24V AS
082H0276
DANFOSS HEATING
AMB 182 15Nm 2-point 60s 24V AS
AMB 182, 24 V AC, 60 s/Rotation angle, 15 N-m
Home > DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
Best sellers
▲More info
▲AMB 182 15Nm 2-point 60s 24V AS
Product details
| Gross weight | 0.846 Kilogram |
| Net weight | 0.643 Kilogram |
| Volume | 2 Liter |
| EAN | 5702428934657 |
| Type | AMB 182 |
| Product group | Gear actuators |
| Gross weight | 0.846 Kilogram |
| Net weight | 0.643 Kilogram |
| Volume | 2 Liter |
| EAN | 5702428934657 |
| Type | AMB 182 |
| Product group | Gear actuators |
| Actuator speed [s/°] | 60 s/Rotation angle |
| Actuator type | Rotary Gear |
| Ambient temperature [°C] [max] | 50 °C |
| Ambient temperature [°C] [min] | 0 °C |
| Approval standard | N/A |
| Auxiliary switch | Yes |
| Cable included | Yes |
| Cable length [m] | 2 m |
| China RoHS compliance | Out of scope |
| Compatibility with valve | HRB 3 DN 15-50 HRB 4 DN 15-50 HRE 3 DN 20-50 HRE 4 DN 20-50 HFE 3 DN 20-150 |
| Contains batteries | No |
| Control input signal Y [mA] | N/A |
| Control input signal Y [V] | N/A |
| Control signal type | 2-point |
| Description | AMB 182 15Nm 2-point 60s 24V AS |
| Electrical Protection Class according to EN60730-1 | III |
| Frequency [Hz] | 50/60 |
| IP protection class | IP42 |
| Manual operation | Yes |
| Operating torque [Nm] | 15 N-m |
| Power consumption [W] | 3.5 W |
| REACH Candidate List substances | No |
| Rotation angle [°] | 90 ° |
| Safety function | No |
| Storage temperature [°C] [Max] | 80 °C |
| Storage temperature [°C] [Min] | -10 °C |
| Supply voltage [V] | 24 V AC |
| Actuator speed [s/°] | 60 s/Rotation angle |
| Actuator type | Rotary Gear |
| Ambient temperature [°C] [max] | 50 °C |
| Ambient temperature [°C] [min] | 0 °C |
| Approval standard | N/A |
| Auxiliary switch | Yes |
| Cable included | Yes |
| Cable length [m] | 2 m |
| China RoHS compliance | Out of scope |
| Compatibility with valve | HRB 3 DN 15-50 HRB 4 DN 15-50 HRE 3 DN 20-50 HRE 4 DN 20-50 HFE 3 DN 20-150 |
| Contains batteries | No |
| Control input signal Y [mA] | N/A |
| Control input signal Y [V] | N/A |
| Control signal type | 2-point |
| Description | AMB 182 15Nm 2-point 60s 24V AS |
| Electrical Protection Class according to EN60730-1 | III |
| Frequency [Hz] | 50/60 |
| IP protection class | IP42 |
| Manual operation | Yes |
| Operating torque [Nm] | 15 N-m |
| Power consumption [W] | 3.5 W |
| REACH Candidate List substances | No |
| Rotation angle [°] | 90 ° |
| Safety function | No |
| Storage temperature [°C] [Max] | 80 °C |
| Storage temperature [°C] [Min] | -10 °C |
| Supply voltage [V] | 24 V AC |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS HEATING EN .pdf | 11 Mbytes |
|
| 082H0276 082H0276 EN_082H0241.pdf | 1 Mbytes |
|
