071N7253 DANFOSS HEATING Oil pump BFP 10 R3R, 1 pipe
Reference: 071N7253
Manufacturer: DANFOSS HEATING
Description:
Oil pump BFP 10 R3R
Oil pump BFP 10 R3R, 1 pipe
Pumps, BFP 10, Biofuel blend: 10
Categories:
- DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
- More Info
- Reviews
LAST VIEWED
MORE INFO
Product Type: BFP 10, Biofuel blend: 10, Rotation: R, Nozzle/pressure outlet: R, Coil voltage [V]: None, AC
Product details
| Gross weight | 1.102 Kilogram |
| Net weight | 1.081 Kilogram |
| Volume | 2.002 Liter |
| EAN | 5702425156496 |
| Type | BFP 10 |
| Product group | Pumps |
| Gross weight | 1.102 Kilogram |
| Net weight | 1.081 Kilogram |
| Volume | 2.002 Liter |
| EAN | 5702425156496 |
| Type | BFP 10 |
| Product group | Pumps |
| Rotation | R |
| 1 or 2 stage | 1 |
| Ambient temperature [°C] [max] | 70 °C |
| Ambient temperature [°C] [min] | -20 °C |
| Approval | CE |
| Biofuel blend | 10 |
| Capacity [l/h] | 24 L/h |
| Capacity group | 0-24 |
| Capacity range [l/h] [Max] | 24 L/h |
| Capacity range [l/h] [Min] | 0 L/h |
| CE evaluated | Out of scope |
| China RoHS compliance | Yes |
| Closing function | None |
| Coil Current | AC |
| Coil voltage [V] | None |
| Comments | Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump. |
| Contains batteries | No |
| Definition point [l/h] | 2800 min-1, 10 bar, 4.3 cSt |
| Description | Oil pump BFP 10 R3R |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Factory pressure setting [bar] | 10 bar |
| Filter area [cm²] | 13 cm² |
| Filter grade [µm] | 200 |
| Filter type | Ring |
| Flats/key on the shaft | 1 flat |
| Media temperature [°C] [Max] | 70 °C |
| Media temperature [°C] [Min] | 0 °C |
| Nozzle/pressure outlet | R |
| Number of stages | 1 |
| Oil pump speed [op/min] | 3450 op/min |
| Oil type | Kerosene/Light oil |
| Packing format | Multi pack |
| Pipe connection | 1 pipe |
| Power consumption [W] | 42 W |
| Pressure [bar] [Max] | 15 bar |
| Pressure [bar] [Min] | 7 bar |
| Pressure feed line [bar] [Max] | 2 bar |
| Pressure kerosene [bar] [Max] | 12 bar |
| Quantity per packing format | 10 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | ff0e1a65-ddc6-4053-a09d-cf25c8023dba |
| SCIP dossier product name | Oil pump BFP 10 R3R, 1 pipe |
| Serie | BFP |
| Shaft diameter [mm] | 8 mm |
| Speed [rpm] [Max] | 3450 rpm |
| Speed [rpm] [Min] | 2400 rpm |
| Starting torque [Nm] [Max] | 0.1 N-m |
| Storage temperature [°C] [Max] | 70 °C |
| Storage temperature [°C] [Min] | -20 °C |
| Suction Line Vacuum [bar] [Max] | 0.4 bar |
| UL evaluated | Out of scope |
| Viscosity [cSt] [Max] | 12 cSt |
| Viscosity [cSt] [Min] | 1.3 cSt |
| Rotation | R |
| 1 or 2 stage | 1 |
| Ambient temperature [°C] [max] | 70 °C |
| Ambient temperature [°C] [min] | -20 °C |
| Approval | CE |
| Biofuel blend | 10 |
| Capacity [l/h] | 24 L/h |
| Capacity group | 0-24 |
| Capacity range [l/h] [Max] | 24 L/h |
| Capacity range [l/h] [Min] | 0 L/h |
| CE evaluated | Out of scope |
| China RoHS compliance | Yes |
| Closing function | None |
| Coil Current | AC |
| Coil voltage [V] | None |
| Comments | Rotation and nozzle/pressure outlet are always determined viewing from the shaft end of the pump. |
| Contains batteries | No |
| Definition point [l/h] | 2800 min-1, 10 bar, 4.3 cSt |
| Description | Oil pump BFP 10 R3R |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Factory pressure setting [bar] | 10 bar |
| Filter area [cm²] | 13 cm² |
| Filter grade [µm] | 200 |
| Filter type | Ring |
| Flats/key on the shaft | 1 flat |
| Media temperature [°C] [Max] | 70 °C |
| Media temperature [°C] [Min] | 0 °C |
| Nozzle/pressure outlet | R |
| Number of stages | 1 |
| Oil pump speed [op/min] | 3450 op/min |
| Oil type | Kerosene/Light oil |
| Packing format | Multi pack |
| Pipe connection | 1 pipe |
| Power consumption [W] | 42 W |
| Pressure [bar] [Max] | 15 bar |
| Pressure [bar] [Min] | 7 bar |
| Pressure feed line [bar] [Max] | 2 bar |
| Pressure kerosene [bar] [Max] | 12 bar |
| Quantity per packing format | 10 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | ff0e1a65-ddc6-4053-a09d-cf25c8023dba |
| SCIP dossier product name | Oil pump BFP 10 R3R, 1 pipe |
| Serie | BFP |
| Shaft diameter [mm] | 8 mm |
| Speed [rpm] [Max] | 3450 rpm |
| Speed [rpm] [Min] | 2400 rpm |
| Starting torque [Nm] [Max] | 0.1 N-m |
| Storage temperature [°C] [Max] | 70 °C |
| Storage temperature [°C] [Min] | -20 °C |
| Suction Line Vacuum [bar] [Max] | 0.4 bar |
| UL evaluated | Out of scope |
| Viscosity [cSt] [Max] | 12 cSt |
| Viscosity [cSt] [Min] | 1.3 cSt |
