065B2056 DANFOSS HEATING VB 2 PN25 15/4 2-way seated flange
065B2056
DANFOSS HEATING
VB 2 PN25 15/4 2-way seated flange
VB 2, PN 25, DN 15, 4 m³/h, Flange
Home > DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
Best sellers
▲More info
▲VB 2 PN25 15/4 2-way seated flange
Product details
| Gross weight | 3.956 Kilogram |
| Net weight | 3.956 Kilogram |
| Volume | 4.921 Liter |
| EAN | 5702421508442 |
| Type | VB 2 |
| Product group | Motorized control valves |
| Gross weight | 3.956 Kilogram |
| Net weight | 3.956 Kilogram |
| Volume | 4.921 Liter |
| EAN | 5702421508442 |
| Type | VB 2 |
| Product group | Motorized control valves |
| Application | District Heating |
| Application alternative VSP | Heating |
| Cavitation factor | 0.5 |
| Cavitation factor 100% | 0.34 |
| Cavitation factor 25% | 0.58 |
| Cavitation factor 50% | 0.52 |
| Cavitation factor 75% | 0.5 |
| China RoHS compliance | Out of scope |
| Connection types | Flange |
| Contains batteries | No |
| Control ratio | 50:1 |
| Description | VB 2 PN25 15/4 2-way seated flange |
| Diameter [mm] | 15 mm |
| Differential pressure range [bar] [Max] | 16 bar |
| EU RoHS compliance | Yes with exemptions |
| Flow characteristic | Split |
| Function | Pressure relief |
| Kvs values [m³/h] | 4 m³/h |
| Leakage through port max. [% Kvs] | 0.05 |
| Media pH [Max] | 10 |
| Media pH [Min] | 7 |
| Media temperature [°C] [Max] | 150 °C |
| Media temperature [°C] [Min] | 2 °C |
| Medium alternative | Glycolic water up to 30% |
| Number of ports | 2 |
| Permissible media | District heating/cooling circulation water |
| PN alternative VSP | 16 |
| Pressure class | PN 25 |
| Pressure nominal [bar] | 25 bar |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | f352afa4-59ce-4256-8962-71c2d32dc0ea |
| SCIP dossier product name | VB 2 PN25 15-x 2-way seated flange |
| Spindle position | Normally open |
| Stroke [mm] | 5 mm |
| Stuffing box sealing material | EPDM |
| Valve body material | Ductile cast iron EN-GJS-400-18-LT (GGG 40.3) |
| Valve cone material | Stainless steel |
| Valve seat material | Stainless steel |
| Valve size | DN 15 |
| Valve stem material | Stainless steel |
| Application | District Heating |
| Application alternative VSP | Heating |
| Cavitation factor | 0.5 |
| Cavitation factor 100% | 0.34 |
| Cavitation factor 25% | 0.58 |
| Cavitation factor 50% | 0.52 |
| Cavitation factor 75% | 0.5 |
| China RoHS compliance | Out of scope |
| Connection types | Flange |
| Contains batteries | No |
| Control ratio | 50:1 |
| Description | VB 2 PN25 15/4 2-way seated flange |
| Diameter [mm] | 15 mm |
| Differential pressure range [bar] [Max] | 16 bar |
| EU RoHS compliance | Yes with exemptions |
| Flow characteristic | Split |
| Function | Pressure relief |
| Kvs values [m³/h] | 4 m³/h |
| Leakage through port max. [% Kvs] | 0.05 |
| Media pH [Max] | 10 |
| Media pH [Min] | 7 |
| Media temperature [°C] [Max] | 150 °C |
| Media temperature [°C] [Min] | 2 °C |
| Medium alternative | Glycolic water up to 30% |
| Number of ports | 2 |
| Permissible media | District heating/cooling circulation water |
| PN alternative VSP | 16 |
| Pressure class | PN 25 |
| Pressure nominal [bar] | 25 bar |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | f352afa4-59ce-4256-8962-71c2d32dc0ea |
| SCIP dossier product name | VB 2 PN25 15-x 2-way seated flange |
| Spindle position | Normally open |
| Stroke [mm] | 5 mm |
| Stuffing box sealing material | EPDM |
| Valve body material | Ductile cast iron EN-GJS-400-18-LT (GGG 40.3) |
| Valve cone material | Stainless steel |
| Valve seat material | Stainless steel |
| Valve size | DN 15 |
| Valve stem material | Stainless steel |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS HEATING EN .pdf | 11 Mbytes |
|
| 065B2056 065B2056 EN_065B2015.pdf | 1 Mbytes |
|
