030H8860 DANFOSS HEATING Nozzle 0.55 gph 80° H CEN Blister
030H8860
DANFOSS HEATING
50
Nozzle 0.55 gph 80° H CEN Blister
Oil Nozzles, OD H, 0.55 gal/h, 2.11 kg/h, 80 °, Hollow
Home > DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
Best sellers
▲More info
▲0.55GAL 80H CEN - 50 PCS. BLISTER
Product details
| Gross weight | 0.032 Kilogram |
| Net weight | 0.031 Kilogram |
| Volume | 0.023 Liter |
| EAN | 5702425049606 |
| Type | OD H |
| Product group | Oil Nozzles |
| Gross weight | 0.032 Kilogram |
| Net weight | 0.031 Kilogram |
| Volume | 0.023 Liter |
| EAN | 5702425049606 |
| Type | OD H |
| Product group | Oil Nozzles |
| Capacity [kg/h] | 2.11 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 0.55 gal/h |
| CE evaluated | Out of scope |
| CEN | Yes |
| China RoHS compliance | Yes |
| Contains batteries | No |
| Description | 0.55GAL 80H CEN - 50 PCS. BLISTER |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 45 |
| Filter type | Sinter |
| LE anti-drip valve | No |
| Packing format | Industrial pack |
| Quantity per packing format | 50 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | ecac5e6b-f9a1-496f-a813-010fd3b09c53 |
| SCIP dossier product name | 30 H F OEM - Nozzle 0.30-0.60 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 80 ° |
| Spray pattern | Hollow |
| spray pattern marking | H |
| UL evaluated | Out of scope |
| Capacity [kg/h] | 2.11 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 0.55 gal/h |
| CE evaluated | Out of scope |
| CEN | Yes |
| China RoHS compliance | Yes |
| Contains batteries | No |
| Description | 0.55GAL 80H CEN - 50 PCS. BLISTER |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 45 |
| Filter type | Sinter |
| LE anti-drip valve | No |
| Packing format | Industrial pack |
| Quantity per packing format | 50 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | ecac5e6b-f9a1-496f-a813-010fd3b09c53 |
| SCIP dossier product name | 30 H F OEM - Nozzle 0.30-0.60 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 80 ° |
| Spray pattern | Hollow |
| spray pattern marking | H |
| UL evaluated | Out of scope |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS HEATING EN .pdf | 11 Mbytes |
|
| 030H8860 030H8860 EN_030F8152.pdf | 448 Kbytes |
|
