030F6876 DANFOSS HEATING Nozzle 1.35 gph 60° S CEN Blister
030F6876
DANFOSS HEATING
50
Nozzle 1.35 gph 60° S CEN Blister
Oil Nozzles, OD S, 1.35 gal/h, 5.17 kg/h, 60 °, Solid
Home > DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
Best sellers
▲More info
▲1.35GAL 60S CEN - 50 PCS. BLISTER
Product details
| Gross weight | 0.03 Kilogram |
| Net weight | 0.029 Kilogram |
| Volume | 0.023 Liter |
| EAN | 5702425049309 |
| Gross weight | 0.03 Kilogram |
| Net weight | 0.029 Kilogram |
| Volume | 0.023 Liter |
| EAN | 5702425049309 |
| Approval | CE |
| Capacity [kg/h] | 5.17 kg/h |
| Capacity [kW] | 0 kW |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 1.35 gal/h |
| CE evaluated | Yes |
| CEN | Yes |
| China RoHS compliance | Out of scope |
| Description | 1.35GAL 60S CEN - 50 PCS. BLISTER |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 75 |
| Filter type | Sinter |
| In scope of WEEE and contain batteries | No |
| LE anti-drip valve | No |
| Packing format | Industrial pack |
| Product group | Oil Nozzles |
| Quantity per packing format | 50 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | 6725389d-11e0-40d3-bb67-825b8ae390a8 |
| SCIP dossier product name | 30 H F OEM - Nozzle 0.65-5.00 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 60 ° |
| Spray pattern | Solid |
| spray pattern marking | S |
| Type | OD S |
| UK RoHS compliance | Yes with exemptions |
| UK RoHS exemption clause | 12 18 |
| UL evaluated | Out of scope |
| Approval | CE |
| Capacity [kg/h] | 5.17 kg/h |
| Capacity [kW] | 0 kW |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 1.35 gal/h |
| CE evaluated | Yes |
| CEN | Yes |
| China RoHS compliance | Out of scope |
| Description | 1.35GAL 60S CEN - 50 PCS. BLISTER |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 75 |
| Filter type | Sinter |
| In scope of WEEE and contain batteries | No |
| LE anti-drip valve | No |
| Packing format | Industrial pack |
| Product group | Oil Nozzles |
| Quantity per packing format | 50 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | 6725389d-11e0-40d3-bb67-825b8ae390a8 |
| SCIP dossier product name | 30 H F OEM - Nozzle 0.65-5.00 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 60 ° |
| Spray pattern | Solid |
| spray pattern marking | S |
| Type | OD S |
| UK RoHS compliance | Yes with exemptions |
| UK RoHS exemption clause | 12 18 |
| UL evaluated | Out of scope |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS HEATING EN .pdf | 11 Mbytes |
|
| 030F6876 030F6876 EN_030F4908.pdf | 496 Kbytes |
|
