030F6103 DANFOSS HEATING Nozzle 0.35 gph 60° S OD
030F6103
DANFOSS HEATING
10
Nozzle 0.35 gph 60° S OD
Oil Nozzles, OD S, 0.35 gal/h, 1.35 kg/h, 60 °, Solid
Home > DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
Best sellers
▲More info
▲0.35GAL 60S OD
Product details
| Gross weight | 0.034 Kilogram |
| Net weight | 0.033 Kilogram |
| Volume | 0.024 Liter |
| EAN | 5702425042966 |
| Gross weight | 0.034 Kilogram |
| Net weight | 0.033 Kilogram |
| Volume | 0.024 Liter |
| EAN | 5702425042966 |
| Approval | CE UL |
| Capacity [kg/h] | 1.35 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 0.35 gal/h |
| CE evaluated | Yes |
| CEN | No |
| China RoHS compliance | Out of scope |
| Description | 0.35GAL 60S OD |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 30 |
| Filter type | Sinter |
| In scope of WEEE and contain batteries | No |
| LE anti-drip valve | No |
| Material type | Brass |
| Packing format | Industrial pack |
| Product group | Oil Nozzles |
| Quantity per packing format | 10 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | 60443ff0-bca5-4a5e-b5fc-1320efb5ecd5 |
| SCIP dossier product name | 30 H F - Nozzle 0.20-0.60 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 60 ° |
| Spray pattern | Solid |
| spray pattern marking | S |
| Type | OD S |
| UK RoHS compliance | Yes with exemptions |
| UK RoHS exemption clause | 12 18 |
| UL evaluated | Yes |
| Approval | CE UL |
| Capacity [kg/h] | 1.35 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 0.35 gal/h |
| CE evaluated | Yes |
| CEN | No |
| China RoHS compliance | Out of scope |
| Description | 0.35GAL 60S OD |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 30 |
| Filter type | Sinter |
| In scope of WEEE and contain batteries | No |
| LE anti-drip valve | No |
| Material type | Brass |
| Packing format | Industrial pack |
| Product group | Oil Nozzles |
| Quantity per packing format | 10 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | 60443ff0-bca5-4a5e-b5fc-1320efb5ecd5 |
| SCIP dossier product name | 30 H F - Nozzle 0.20-0.60 gph |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 60 ° |
| Spray pattern | Solid |
| spray pattern marking | S |
| Type | OD S |
| UK RoHS compliance | Yes with exemptions |
| UK RoHS exemption clause | 12 18 |
| UL evaluated | Yes |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS HEATING EN .pdf | 11 Mbytes |
|
| 030F6103 030F6103 EN_030F4908.pdf | 496 Kbytes |
|
