030B8803 DANFOSS HEATING Nozzle 0.60 GPH 80° B OD Blister **
030B8803
DANFOSS HEATING
50
Nozzle 0.60 GPH 80° B OD Blister **
Oil Nozzles, OD B, 0.6 gal/h, 2.37 kg/h, 80 °, Semi solid
Home > DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
Best sellers
▲More info
▲0.60 GAL 80° B OD - 50 PCS. BLISTER
Product details
| Gross weight | 0.032 Kilogram |
| Net weight | 0.023 Kilogram |
| Volume | 0.023 Liter |
| EAN | 5702425243264 |
| Type | OD B |
| Product group | Oil Nozzles |
| Gross weight | 0.032 Kilogram |
| Net weight | 0.023 Kilogram |
| Volume | 0.023 Liter |
| EAN | 5702425243264 |
| Type | OD B |
| Product group | Oil Nozzles |
| Capacity [kg/h] | 2.37 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 0.6 gal/h |
| CE evaluated | Out of scope |
| China RoHS compliance | Yes |
| Contains batteries | No |
| Description | 0.60 GAL 80° B OD - 50 PCS. BLISTER |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 45 |
| Filter type | Sinter |
| LE anti-drip valve | No |
| Material type | Brass |
| Packing format | Industrial pack |
| Quantity per packing format | 50 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | bafb82bc-5502-45ef-b71f-d685a25d9a11 |
| SCIP dossier product name | Nozzle 0.60 GPH 80° B OD Blister ** |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 80 ° |
| Spray pattern | Semi solid |
| spray pattern marking | B |
| UL evaluated | Out of scope |
| Capacity [kg/h] | 2.37 kg/h |
| Capacity [l/h] | 0 L/h |
| Capacity [USgal/h] | 0.6 gal/h |
| CE evaluated | Out of scope |
| China RoHS compliance | Yes |
| Contains batteries | No |
| Description | 0.60 GAL 80° B OD - 50 PCS. BLISTER |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(a) 6(a)-I 6(c) |
| Filter grade [µm] | 45 |
| Filter type | Sinter |
| LE anti-drip valve | No |
| Material type | Brass |
| Packing format | Industrial pack |
| Quantity per packing format | 50 pc |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| Reference point | 7 bar, 3.4 cSt, 820 kg/m³ |
| SCIP dossier no. | bafb82bc-5502-45ef-b71f-d685a25d9a11 |
| SCIP dossier product name | Nozzle 0.60 GPH 80° B OD Blister ** |
| Shape | Conical |
| Specification point | 10 bar, 3.4 cSt, 840 kg/m³ |
| Spray angle [°] | 80 ° |
| Spray pattern | Semi solid |
| spray pattern marking | B |
| UL evaluated | Out of scope |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE DANFOSS HEATING EN .pdf | 11 Mbytes |
|
| 030B8803 030B8803 EN_030F8152.pdf | 448 Kbytes |
|
