003Z4035 DANFOSS HEATING MSV-B DN40 G1½" int.
Reference: 003Z4035
Manufacturer: DANFOSS HEATING
Description:
MSV-B DN40 G1½" int.
LENO MSV-B, DN 40, Internal thread
Categories:
- DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
- More Info
- Reviews
* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
- These delivery times are an estimate any may vary when the item order has been processed.
MORE INFO
MSV-B DN 40, Internal thread, manual balancing valve
Product details
| Gross weight | 1.664 Kilogram |
| Net weight | 1.664 Kilogram |
| Volume | 2.19 Liter |
| EAN | 5702420096506 |
| Gross weight | 1.664 Kilogram |
| Net weight | 1.664 Kilogram |
| Volume | 2.19 Liter |
| EAN | 5702420096506 |
| China RoHS compliance | Out of scope |
| Connection types | Internal thread |
| Connections | Rp 1½ |
| Description | MSV-B DN 40, Internal thread, manual balancing valve |
| Drain function | No |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| In scope of WEEE and contain batteries | No |
| Kvs values [m³/h] | 26 m³/h |
| Media temperature [°C] [Max] | 120 °C |
| Media temperature [°C] [Min] | -20 °C |
| Pressure class | PN 20 |
| Product group | Manual balancing |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | e31a4e1f-b706-4ff7-acc3-f3e2d361ce7e |
| SCIP dossier product name | MSV-B DN15-DN50 (1) |
| Setting scale | Yes |
| Shut-off function | Yes |
| Test plugs | With test plugs |
| Type | LENO MSV-B |
| UK RoHS compliance | Out of scope |
| Valve body material | DZR brass |
| Valve size | DN 40 |
| China RoHS compliance | Out of scope |
| Connection types | Internal thread |
| Connections | Rp 1½ |
| Description | MSV-B DN 40, Internal thread, manual balancing valve |
| Drain function | No |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| In scope of WEEE and contain batteries | No |
| Kvs values [m³/h] | 26 m³/h |
| Media temperature [°C] [Max] | 120 °C |
| Media temperature [°C] [Min] | -20 °C |
| Pressure class | PN 20 |
| Product group | Manual balancing |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | e31a4e1f-b706-4ff7-acc3-f3e2d361ce7e |
| SCIP dossier product name | MSV-B DN15-DN50 (1) |
| Setting scale | Yes |
| Shut-off function | Yes |
| Test plugs | With test plugs |
| Type | LENO MSV-B |
| UK RoHS compliance | Out of scope |
| Valve body material | DZR brass |
| Valve size | DN 40 |
