003L6008 DANFOSS HEATING AVDO20 CONSTANT FLOW CONT.
Reference: 003L6008
Manufacturer: DANFOSS HEATING
Description:
AVDO20 CONSTANT FLOW CONT.
Automatic Bypass Control, AVDO, DN 20, Angle, Internal thread, External thread
Categories:
- DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
- More Info
- Reviews
MORE INFO
Self-acting constant flow valve
Product details
| Gross weight | 0.8 Kilogram |
| Net weight | 0.768 Kilogram |
| Volume | 1.032 Liter |
| EAN | 5702420017129 |
| Type | AVDO |
| Product group | Automatic Bypass Control |
| Gross weight | 0.8 Kilogram |
| Net weight | 0.768 Kilogram |
| Volume | 1.032 Liter |
| EAN | 5702420017129 |
| Type | AVDO |
| Product group | Automatic Bypass Control |
| CE evaluated | Out of scope |
| Connection size in | Rp 3/4 |
| Connection size out | R 3/4 |
| Connection types | Threaded |
| Connections | 3/4" |
| Contains batteries | No |
| Description | Self-acting constant flow valve |
| Design | Angle |
| Differential pressure range [bar] [Max] | 0.5 bar |
| EU RoHS compliance | Yes with exemptions |
| Flow temperature [°C] [Max] | 120 °C |
| Inlet connection type | Internal thread |
| Outlet connection type | External thread |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | 8d736b0d-4ef5-4b75-a470-3b3ad31b8da6 |
| SCIP dossier product name | AVDO COMMERCIAL 20 |
| Setting [bar] [Max] | 0.5 bar |
| Setting [bar] [Min] | 0.05 bar |
| UL evaluated | Out of scope |
| Valve size | DN 20 |
| Working pressure [bar] [Max] | 10 bar |
| CE evaluated | Out of scope |
| Connection size in | Rp 3/4 |
| Connection size out | R 3/4 |
| Connection types | Threaded |
| Connections | 3/4" |
| Contains batteries | No |
| Description | Self-acting constant flow valve |
| Design | Angle |
| Differential pressure range [bar] [Max] | 0.5 bar |
| EU RoHS compliance | Yes with exemptions |
| Flow temperature [°C] [Max] | 120 °C |
| Inlet connection type | Internal thread |
| Outlet connection type | External thread |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | 8d736b0d-4ef5-4b75-a470-3b3ad31b8da6 |
| SCIP dossier product name | AVDO COMMERCIAL 20 |
| Setting [bar] [Max] | 0.5 bar |
| Setting [bar] [Min] | 0.05 bar |
| UL evaluated | Out of scope |
| Valve size | DN 20 |
| Working pressure [bar] [Max] | 10 bar |
