003L3585 DANFOSS HEATING AHPBM-F PN16 32/6,3/0,14 ext.thr. flow

Reference: 003L3585

Manufacturer: DANFOSS HEATING

Description:

AHPBM-F PN16 32/6,3/0,14 ext.thr. flow
AHPBM-F, PN 16, DN 32, Flow rate [m³/h]: 0.65 - 3.40, External Thread, G 1 3/4 A, Mounting version: Flow

Categories:

  • DANFOSS HEATING

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

LAST VIEWED

MORE INFO

AHPBM-F PN16 32/6,3/0,14 ext.thr. flow

Product details

Gross weight2.367 Kilogram
Net weight2.15 Kilogram
Volume2.43 Liter
EAN5702421558188
Gross weight2.367 Kilogram
Net weight2.15 Kilogram
Volume2.43 Liter
EAN5702421558188

Actuator diaphragm materialEPDM
ApplicationDistrict Heating
Cavitation factor0.6
Connection sizeG 1 3/4 A
Connection typesExternal Thread
DescriptionAHPBM-F PN16 32/6,3/0,14 ext.thr. flow
Diameter [mm]32 mm
Differential pressure range [bar] [Max]4 bar
Differential pressure setting [bar] [Max]0.14 bar
Differential pressure setting [bar] [Min]0.14 bar
dPb virtual0.1
Flow controlNo
Flow limitationYes
Flow rate [m³/h]3.4 m³/h
Flow rate [m³/h] [Max]3.4 m³/h
Flow rate [m³/h] [Min]0.65 m³/h
FunctionDiff. press. and flow limiter with int. control valve
Function VSP - PYes
Function VSP - QYes
Function VSP - TNo
In scope of WEEE and contain batteriesNo
Kvs values [m³/h]6.3 m³/h
Leakage rate [% Kvs]0.05
Media pH [Max]10
Media pH [Min]7
Media temperature [°C] [Max]120 °C
Media temperature [°C] [Min]2 °C
Medium alternativeGlycolic water up to 30%
Mounting versionFlow
Number of ports2
Permissible mediaDistrict heating/cooling circulation water
PN alternative VSP10
Pressure classPN 16
Pressure controllerDifferential pressure controller
Pressure nominal [bar]16 bar
Product groupPressure flow controllers
REACH Candidate List substancesLead (CAS no. 7439-92-1)
Sealing CV materialEPDM
Sealing DP materialEPDM
Select if the Shock valve should be with a Fixed pressure or AdjustablepressureFixed
Stem positionNormally open
Stroke [mm]5 mm
TypeAHPBM-F
Valve body materialDZR brass CuZn36Pb2AS (CW 602N)
Valve cone CV materialDezincing free brass CuZn36Pb2As
Valve cone DP materialDezincing free brass CuZn36Pb2As
Valve seat materialDezincing free brass CuZn36Pb2As
Valve sizeDN 32
Actuator diaphragm materialEPDM
ApplicationDistrict Heating
Cavitation factor0.6
Connection sizeG 1 3/4 A
Connection typesExternal Thread
DescriptionAHPBM-F PN16 32/6,3/0,14 ext.thr. flow
Diameter [mm]32 mm
Differential pressure range [bar] [Max]4 bar
Differential pressure setting [bar] [Max]0.14 bar
Differential pressure setting [bar] [Min]0.14 bar
dPb virtual0.1
Flow controlNo
Flow limitationYes
Flow rate [m³/h]3.4 m³/h
Flow rate [m³/h] [Max]3.4 m³/h
Flow rate [m³/h] [Min]0.65 m³/h
FunctionDiff. press. and flow limiter with int. control valve
Function VSP - PYes
Function VSP - QYes
Function VSP - TNo
In scope of WEEE and contain batteriesNo
Kvs values [m³/h]6.3 m³/h
Leakage rate [% Kvs]0.05
Media pH [Max]10
Media pH [Min]7
Media temperature [°C] [Max]120 °C
Media temperature [°C] [Min]2 °C
Medium alternativeGlycolic water up to 30%
Mounting versionFlow
Number of ports2
Permissible mediaDistrict heating/cooling circulation water
PN alternative VSP10
Pressure classPN 16
Pressure controllerDifferential pressure controller
Pressure nominal [bar]16 bar
Product groupPressure flow controllers
REACH Candidate List substancesLead (CAS no. 7439-92-1)
Sealing CV materialEPDM
Sealing DP materialEPDM
Select if the Shock valve should be with a Fixed pressure or AdjustablepressureFixed
Stem positionNormally open
Stroke [mm]5 mm
TypeAHPBM-F
Valve body materialDZR brass CuZn36Pb2AS (CW 602N)
Valve cone CV materialDezincing free brass CuZn36Pb2As
Valve cone DP materialDezincing free brass CuZn36Pb2As
Valve seat materialDezincing free brass CuZn36Pb2As
Valve sizeDN 32
