DANFOSS HEATING 003L0453 003L0453 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

003L0453 DANFOSS HEATING RLV-S 15 angle Ext. thread

Name: 003L0453 DANFOSS HEATING RLV-S 15 angle Ext. thread
Brand: DANFOSS HEATING
SKU: DAS003L0453
Price: 9.41 USD
Availability: OutOfStock

Reference: 003L0453

Manufacturer: DANFOSS HEATING

Description:

RLV-S 15 angle Ext. thread

Lockshield Valves, RLV-S, DN 15, Angle, Standard, External Thread

Categories:

DANFOSS HEATING

Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING

More Info
PDF
Reviews

Guarantee, repair and return.

Unit Price: 8,41 €

This price is per unit and is the net value (not including taxes if applicable).

Special discounts for registered customers.Login or register and prices will be updated.

Calculate price by quantity

Quantity	Price

Standard lead time: 10 days.

These delivery times are an estimate any may vary when the item order has been processed.
You will be notified of any change to delivery times once the order has been processed.
To this delivery time you have to add the time of transport from our logistics centre to your company.

MORE INFO

Lockshield with external thread valve body

Product details

Gross weight	113 Gram
Net weight	107 Gram
Volume	0.057 Liter

EAN	5702425149689
Type	RLV-S
Product group	Lockshield Valves

Gross weight	113 Gram
Net weight	107 Gram
Volume	0.057 Liter
EAN	5702425149689
Type	RLV-S
Product group	Lockshield Valves

CE evaluated	Out of scope
China RoHS compliance	Out of scope
Connection to radiator	G 3/4 A
Connection to system	Rp 1/2
Connection types	External Thread
Contains batteries	No
Description	Lockshield with external thread valve body
Design	Angle
EU RoHS compliance	Yes with exemptions
EU RoHS exemption clause	6(c)
Finish	Nickel plated

Flow temperature [°C] [Max]	120 °C
Kvs values [m³/h]	2.2 m³/h
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
SCIP dossier no.	7137db49-55ea-470c-ba5d-28b3fb1ea9e6
SCIP dossier product name	RLV-S Lock shield 1
Surface	Nickel plated
Tailpiece type	Standard
Test pressure [bar]	16 bar
UL evaluated	Out of scope
Valve size	DN 15
Working pressure [bar] [Max]	10 bar

CE evaluated	Out of scope
China RoHS compliance	Out of scope
Connection to radiator	G 3/4 A
Connection to system	Rp 1/2
Connection types	External Thread
Contains batteries	No
Description	Lockshield with external thread valve body
Design	Angle
EU RoHS compliance	Yes with exemptions
EU RoHS exemption clause	6(c)
Finish	Nickel plated
Flow temperature [°C] [Max]	120 °C
Kvs values [m³/h]	2.2 m³/h
REACH Candidate List substances	Lead (CAS no. 7439-92-1)
SCIP dossier no.	7137db49-55ea-470c-ba5d-28b3fb1ea9e6
SCIP dossier product name	RLV-S Lock shield 1
Surface	Nickel plated
Tailpiece type	Standard
Test pressure [bar]	16 bar
UL evaluated	Out of scope
Valve size	DN 15
Working pressure [bar] [Max]	10 bar

DATASHEET - PDF

Title

Size

Type

003L0453 003L0453 EN_003L0121.pdf

218 Kbytes

PDF CATALOGUE DANFOSS HEATING EN

11 Mbytes
