003L0223 DANFOSS HEATING RLV-KS 3/4" Angle, nickel-plated
Reference: 003L0223
Manufacturer: DANFOSS HEATING
Description:
RLV-KS 3/4" Angle, nickel-plated
H-piece valves, RLV-KS, 20, Angle
Categories:
- DANFOSS HEATING
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS HEATING
- More Info
- Reviews
* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.
LAST VIEWED
MORE INFO
Standard H-piece with shut-off
Product details
| Gross weight | 0.3 Kilogram |
| Net weight | 0.297 Kilogram |
| Volume | 0.166 Liter |
| EAN | 5702420035925 |
| Type | RLV-KS |
| Product group | H-piece valves |
| Gross weight | 0.3 Kilogram |
| Net weight | 0.297 Kilogram |
| Volume | 0.166 Liter |
| EAN | 5702420035925 |
| Type | RLV-KS |
| Product group | H-piece valves |
| Application | 2-pipe system |
| CE evaluated | Out of scope |
| China RoHS compliance | Out of scope |
| Connection to radiator | G 3/4 A |
| Connection to system | G 3/4 |
| Contains batteries | No |
| Description | Standard H-piece with shut-off |
| Design | Angle |
| Distance center to center [mm] | 50 mm |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Flow temperature [°C] [Max] | 120 °C |
| Kvs values [m³/h] | 1.3 m³/h |
| Label product | Yes |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | a3e070d0-c614-4063-a8f9-af2a0b7733b5 |
| SCIP dossier product name | RLV-KS, H-piece |
| Surface | Nickel plated |
| Test pressure [bar] | 16 bar |
| UL evaluated | Out of scope |
| Valve size | 20 |
| Working pressure [bar] [Max] | 10 bar |
| Application | 2-pipe system |
| CE evaluated | Out of scope |
| China RoHS compliance | Out of scope |
| Connection to radiator | G 3/4 A |
| Connection to system | G 3/4 |
| Contains batteries | No |
| Description | Standard H-piece with shut-off |
| Design | Angle |
| Distance center to center [mm] | 50 mm |
| EU RoHS compliance | Yes with exemptions |
| EU RoHS exemption clause | 6(c) |
| Flow temperature [°C] [Max] | 120 °C |
| Kvs values [m³/h] | 1.3 m³/h |
| Label product | Yes |
| REACH Candidate List substances | Lead (CAS no. 7439-92-1) |
| SCIP dossier no. | a3e070d0-c614-4063-a8f9-af2a0b7733b5 |
| SCIP dossier product name | RLV-KS, H-piece |
| Surface | Nickel plated |
| Test pressure [bar] | 16 bar |
| UL evaluated | Out of scope |
| Valve size | 20 |
| Working pressure [bar] [Max] | 10 bar |
DATASHEET - PDF
Title
Size
Type
530 Kbytes
11 Mbytes
