134X7355 DANFOSS DRIVES VLT AQUA Drive FC 202
134X7355
DANFOSS DRIVES
VLT AQUA Drive FC 202
Frequency converterFC-202P1K5T2E55H2XGX7SXSXXXXAXBXCXXXXDX VLT® AQUA Drive FC-202(P1K5) 1.5 KW / 2.0 HP, Three phase, 200 - 240 VAC, IP55 / Type 12RFI FilterNo brake chopperGraphical Loc. Cont. PanelNot coated PCB, FuseLatest release std. SW.Frame: A5No A Option, No B OptionNo C1 option, No D optionOther options according to Model code
VLT AQUA FC202 - DANFOSS DRIVES
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS DRIVES
Best sellers
▲More info
▲Frequency converter
FC-202P1K5T2E55H2XGX7SXSXXXXAXBXCXXXXDX
VLT® AQUA Drive FC-202
(P1K5) 1.5 KW / 2.0 HP,
Three phase, 200 - 240 VAC, IP55 / Type 12
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB, Fuse
Latest release std. SW.
Frame: A5
No A Option, No B Option
No C1 option, No D option
Other options according to Model code
Product details
| Gross weight | 11.526 Kilogram | ||
| Net weight | 10.91 Kilogram | ||
| Volume | 65.101 Liter | ||
| EAN | 5710108135164 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® AQUA Drive FC- | |
| Series | 202 | 202 | |
| Power Rating | P1K5 | (P1K5) 1.5 KW / 2.0 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 2 | 200 - 240 VAC | |
| Enclosure | E55 | IP55 / Type 12 | |
| RFI Filter | H2 | RFI Filter | |
| Brake - Safe Stop | X | No brake chopper | |
| LCP | G | Graphical Loc. Cont. Panel | |
| Coating PCB | X | Not coated PCB | |
| Mains Option | 7 | Fuse | |
| Adaptation A | S | Smooth imperial cable entr | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | AX | No A Option | |
| B Option | BX | No B Option | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | X | No C1 option | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | A5 | A5 | |
| Typecode Part 1 | FC-202P1K5T2E55H2XGX | ||
| Typecode Part 2 | 7SXSXXXXAXBXCXXXXDX | ||
| Product Catalog | NO_VIEW | NO VIEW | |
| Power 150% (HO) [KW] | 1.5 | 1.5 | |
| Power 110% (NO) [KW] | 1.5 | 1.5 | |
| Height [mm] | 420,0 | 420,0 | |
| Width w/ no C options [mm] | 242,0 | 242,0 | |
| Depth [mm] | 200,0 | 200,0 | |
| Depth with Option A/B [mm] | 200,0 | 200,0 | |
| kVA | 2.7 | 2.7 | |
| Power Loss NO [W] | 82 | 82 | |
| Continuous Current (NO) [A] | 7.5 | 7.5 | |
| Intermittent Current (NO) [A] | 8.25 | 8.25 | |
| Calculated Gross Weight [kg] | 11.526 | ||
| Calculated Net Weight [kg] | 10.91 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Recommended Factory | ERR01 | Cannot Determine Vendor | |
| Modelcode01 | FC-202P1K5T2E55H2XGX | ||
| Modelcode02 | 7SXSXXXXAXBXCXXXXDX | ||
| Recommended Plant | ERR01 | ERR01 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF VLT AQUA Drive FC 202 2024 EN.pdf | 51 Mbytes |
|
| PDF CATALOG DANFOSS GENERAL EN.pdf | 2 Mbytes |
|
