131X4119 DANFOSS DRIVES VLT AQUA Drive FC 202
131X4119
DANFOSS DRIVES
VLT AQUA Drive FC 202
Frequency converterFC-202P22KT7E21H2XGXXXXSXXXXAXBXCXXXXDX VLT® AQUA Drive FC-202(P22K) 22 KW / 30 HP, 18.5kW@525- 550V, 25HP@575V, 22kW@690VThree phase, 525 - 690 VAC *, IP21 / Type 1RFI FilterNo brake chopperGraphical Loc. Cont. PanelNot coated PCB, No Mains OptionLatest release std. SW.Frame: B2No A Option, No B OptionNo C1 option, No D optionOther options according to Model code
VLT AQUA FC202 - DANFOSS DRIVES
Brand new product in its original packaging covered by the warranties and certifications provided by DANFOSS DRIVES
Best sellers
▲More info
▲Frequency converter
FC-202P22KT7E21H2XGXXXXSXXXXAXBXCXXXXDX
VLT® AQUA Drive FC-202
(P22K) 22 KW / 30 HP, 18.5kW@525- 550V, 25HP@575V, 22kW@690V
Three phase, 525 - 690 VAC *, IP21 / Type 1
RFI Filter
No brake chopper
Graphical Loc. Cont. Panel
Not coated PCB, No Mains Option
Latest release std. SW.
Frame: B2
No A Option, No B Option
No C1 option, No D option
Other options according to Model code
Product details
| Gross weight | 31.05 Kilogram | ||
| Net weight | 27.49 Kilogram | ||
| Volume | 105.71 Liter | ||
| EAN | 5710107060849 |
| Product View (Switch) | GLBL | Global (Standard) | |
| Product Group | FC- | VLT® AQUA Drive FC- | |
| Series | 202 | 202 | |
| Power Rating | P22K | (P22K) 22 KW / 30 HP | |
| Phase | T | Three phase | |
| Mains Voltage | 7 | 525 - 690 VAC * | |
| Possible rating issue | WARN01 | Possible Rating Issue: | |
| Enclosure | E21 | IP21 / Type 1 | |
| RFI Filter | H2 | RFI Filter | |
| Brake - Safe Stop | X | No brake chopper | |
| LCP | G | Graphical Loc. Cont. Panel | |
| Coating PCB | X | Not coated PCB | |
| Mains Option | X | No Mains Option | |
| Adaptation A | X | Standard Cable Entries | |
| Adaptation B | X | No adaptation | |
| Software Release | SXXX | Latest release std. SW. | |
| Software Language Pack | X | Standard Language Pack | |
| A Option | AX | No A Option | |
| B Option | BX | No B Option | |
| C0 Option MCO | CX | No C0 option | |
| C1 Option | X | No C1 option | |
| C Option Software | XX | No software option | |
| D Option | DX | No D option | |
| Frame Size | B2 | B2 | |
| Typecode Part 1 | FC-202P22KT7E21H2XGX | ||
| Typecode Part 2 | XXXSXXXXAXBXCXXXXDX | ||
| Product Catalog | NO_VIEW | NO VIEW | |
| Power 160% (HO) [KW] | 18.5 | 18.5 | |
| Power 110% (NO) [KW] | 22 | 22 | |
| Height [mm] | 664,0 | 664,0 | |
| Width w/ no C options [mm] | 243,0 | 243,0 | |
| Depth [mm] | 261,0 | 261,0 | |
| Depth with Option A/B [mm] | 261,0 | 261,0 | |
| kVA | 32.3 | 32.3 | |
| Power Loss NO [W] | 370 | 370 | |
| Power Loss NO [W] | 370 | 370 | |
| Power Loss HO [W] | 300 | 300 | |
| Power Loss HO [W] | 300 | 300 | |
| Continuous Current (NO) [A] | 28 | 28 | |
| Intermittent Current (NO) [A] | 30.8 | 30.8 | |
| Continuous Current (NO) [A] | 27 | 27 | |
| Intermittent Current (NO) [A] | 29.7 | 29.7 | |
| Continuous Current (HO) [A] | 23 | 23 | |
| Intermittent Current (HO) [A] | 36.8 | 36.8 | |
| Continuous Current (HO) [A] | 22 | 22 | |
| Intermittent Current (HO) [A] | 35.2 | 35.2 | |
| Power Rating at 525-550V | 18.5kW | 18.5kW | |
| Power Rating at 575V | 25HP | 25HP | |
| Power Rating at 690V | 22kW | 22kW | |
| Calculated Gross Weight [kg] | 31.05 | ||
| Calculated Net Weight [kg] | 27.49 | ||
| ECCN EU | Y901 | Y901 | |
| ECCN US | 3A999.a | 3A999.a | |
| Vendor | ERR01 | Cannot Determine Vendor | |
| Producing plant | ERR01 | Cannot Determine Vendor | |
| Modelcode01 | FC-202P22KT7E21H2XGX | ||
| Modelcode02 | XXXSXXXXAXBXCXXXXDX | ||
| Delivering plant | ERR01 | ERR01 |
