BTICINOLIVING NOW WITH NETATMOKM41 BTCINO LNWN COMMAND KEY D/N 1M SAND
BTICINO KM41 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

KM41 BTCINO LNWN COMMAND KEY D/N 1M SAND

Code: KM41

Manufacturer: BTICINO

Description:

LNWN COMMAND KEY D/N 1M SAND
2P+T Living Now Base - Italian standard - screw connection - Sand - 1 module
Living Now w/Netatmo key for wireless command "Day/Night" - Sand - 1mod

Categories:

  • Domestic switching devices > Control element/cover plate for domestic switching devices
  • BTICINO > LIVING NOW WITH NETATMO

Brand new product in its original packaging covered by the warranties and certifications provided by BTICINO

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

Total: 45,25 €

Unit Price: 4,525 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 15-17 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

Italian standard 2P+T bases - 10A - 250 Vac - Distance between alveoli of 19mm - Screw connection - With protection shutters - 1 module -To be combined with KM02 front, support and decorative plate - Sand.
ModelItalian Type P11
Protective contactRound
Number of active (round) contacts1
Number of active contacts (drawings)0
Type of mountingBasic element with center cover plate, Recessed mounted (plaster)
With signal lampNo
Number of USB-A ports0
Number of USB-C ports0
Number of sockets1
Phase-separated power outletsNo
Number of modules (in case of modular design)1
Number of interchangeable sockets0
Number of phases1
Printing/MarkingOther
Connection MethodScrew-on terminal
With flip-top lidNo
With enhanced contact protectionYes
Label Space/Print AreaNo
ColourBeige
RAL number (similar)1013
Metallic colorNo
TransparentNo
LockableNo
Expulsion mechanismNo
Isolated installationNo
With functional lightingNo
With adjustable lightingNo
Surge protectionNo
Residual Current DeviceNo
With microfusionNo
Special power supplynone
Attachment TypeHemming
MaterialPlastic
Material qualityThermoplastic
Halogen-freeYes
Surface treatmentNo treatment
Surface FinishMate
Antibacterial treatmentNo
With loop functionNo
With on/off switchNo
Rotated center insertNo
Nominal intensity10 A
Nominal Voltage250 V
frequency45-55 Hz
Suitable for protection grade (IP)IP20
Impact resistanceOther
Device width22 mm
Device height45 mm
Device Depth38 mm
Min. depth of the recessed box38 mm
Compatible with Apple HomeKitNo
Compatible with Amazon AlexaNo
Compatible with Google AssistantNo
Compatible IFTTTNo
With Wi-Fi signal repeaterNo
With built-in bluetooth speakerNo
For server conditions according to VDENo
Installation Depth28 mm
Operating Temperature-5-35 °C
Storage temperature-5-35 °C
Type of voltageAC
Power DeliveryNo
PrewiredNo
Terminal capacity2.5-4 mm²
Connection Cable TypeFlexible or rigid
Core cross-section2.5-4 mm²
Cable HolderCable glands
Connected ObjectNo

ETIM for KM41 Domestic wiring accessories and controls (EC000011)

Feature nameHeight (EF000040)
Feature value86 mm
Feature nameRAL-number (similar) (EF003882)
Feature value1015
Feature nameModel (EF000010)
Feature valueOne-part rocker
Feature nameSuitable for touch sensor connector for bus system (EF007802)
Feature valueNo
Feature nameMaterial (EF002169)
Feature valuePlastic
Feature nameUtilization (EF000133)
Feature valueSwitch/push button
Feature nameMonitoring window/light outlet (EF003864)
Feature valueYes
Feature nameSurface finishing (EF006569)
Feature valueMatt
Feature nameType of fastening (EF002442)
Feature valueEngage (snap)
Feature nameMaterial quality (EF001257)
Feature valueThermoplastic
Feature nameHalogen free (EF000025)
Feature valueYes
Feature nameWith exchangeable lens/symbol (EF006039)
Feature valueNo
Feature nameWith label area (EF005040)
Feature valueNo
Feature nameScannable symbol/barrier free (EF012306)
Feature valueNo
Feature nameAnti-bacterial treatment (EF023790)
Feature valueNo
Feature nameImpact strength (EF004293)
Feature valueIK04
Feature nameImprint/indication (EF003823)
Feature valueVarious symbols
Feature nameDepth (EF000049)
Feature value7 mm
Feature nameColour (EF000007)
Feature valueBeige
Feature nameSurface protection (EF000139)
Feature valueUntreated
Feature nameWidth (EF000008)
Feature value22 mm

DATASHEET - PDF

Title
Size
Type
PDF CATALOGUE BTICINO EN
19 Mbytes
