BT-374004 BTCINO BT/IP-SMALL KEYBOARD BOARD
Code: BT-374004
Manufacturer: BTICINO
Description:
BT/IP-SMALL KEYBOARD BOARD
BT/IP-INNER BOARD WITH SMALL KEYBOARD
Categories:
- BTICINO
Brand new product in its original packaging covered by the warranties and certifications provided by BTICINO
- More Info
- Reviews
LAST VIEWED
MORE INFO
Small plate for indoor installation with card reader and capacitive keys to call the monitor and concierge center.
| Number of Ring/Ring Buttons | 0 |
|---|---|
| Front material | Other |
| Front Panel Height | 193 mm |
| Faceplate width | 94 mm |
| Installation height | 178 mm |
| Mounting width | 84 mm |
| Installation Depth | 59 mm |
| Type of mounting | Recessed mounted (plaster) |
| Installation technology | Network Technology |
| Modular design | No |
| Colour | Silver |
| Protection Class (IP) | IP54 |
| Impact resistance | IK07 |
| Operating Temperature (Min-Max) | -40-70 °C |
| Storage Temperature (Min-Max) | -40-70 °C |
| Type of voltage | CC |
| Nominal Voltage (Min-Max) | 24-24 V |
| Rated Current (Min-Max) | 0.65-0.65 A |
| Halogen-free | Yes |
| Connection Cable Type | Flexible or rigid |
| Core Cross Section (Min-Max) | 0.8-0.8 mm² |
| Label Space/Print Area | No |
|---|---|
| Equipped with waterproof plate protection | No |
| With signal lamp | No |
| Contains battery and/or accumulator | No |
| Hands-free | Yes |
| Volume control | Yes |
| Addressable | Yes |
| Doorman with mobile app | No |
| Remote opening of the electric gate/door opener | Yes |
| Camera Type | Night vision |
| Camera viewing angle | 80 ° |
| Communication Classification Type | Other |
| Connected Object | Yes |
| Method of operation | Net |
| App download platform | App Store, Google Play Store |
| With voice command | No |
| Programmable | Yes |
| Programming medium | Web software |
| Possibility of connection via Internet box | No |
| App Name | Home + Security |
| Product usage function | Automatic intercoms |
