BTICINO 3476 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

3476 BTCINO ACTING-COMMAND BASIC SCS 1RELE

Code: 3476

Manufacturer: BTICINO

Description:

ACTING-COMMAND BASIC SCS 1RELE
ACTUA-COMANDO BASIC SCS 1RELE
DPX³ 250 HP 4 Pole 100A S10 Electronic Release MCCB with Energy Metering Central Unit and Earth Leakage Module 36kA
Control actuator 1 relay MyHOME - basic format

Categories:

  • Installation bus systems > Switch actuator for bus system
  • BTICINO > DOMOTICS MY HOME

Brand new product in its original packaging covered by the warranties and certifications provided by BTICINO

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 159,71 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 15-17 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Rated permanent current Iu100 A
Rated voltage230-690 V
Rated short-circuit breaking capacity Icu at 400 V, 50 Hz36 kA
Overload release current setting40-100 A
Adjustment range undelayed short-circuit release150-1000 A
Device constructionBuilt-in device fixed built-in technique
Integrated earth fault protectionYes
Type of electrical connection of main circuitBolt connection
Suitable for DIN rail (top hat rail) mountingNo
DIN rail (top hat rail) mounting optionalNo
Number of auxiliary contacts as change-over contact2
With switched-off indicatorYes
With integrated under voltage releaseNo
Number of poles4
Position of connection for main current circuitFront side
Type of control elementWing knob
Complete device with protection unitYes
Motor drive integratedNo
Motor drive optionalYes
Degree of protection (IP)IP30
Width140 mm
Height165 mm
Depth112 mm
degree of impact strength (IK)Not applicable
Operating / setting temperature-5-70 °C
Storage temperature-25-85 °C
Voltage typeAC
Frequency50-60 Hz
Electric supplying directionNot applicable
Terminal marking indicationNo
ColourGrey
RAL-number7035
Halogen freeYes
Terminals capacity2.5-120 mm²
Cable nature for connectionFlexible or rigid
Label space/information surfaceNo

ETIM for 3476 Installation bus systems (EC001097)

Feature nameWith LED indication (EF005950)
Feature valueYes
Feature nameDegree of protection (IP) (EF005474)
Feature valueIP20
Feature nameNumber of digital inputs (EF001992)
Feature value1
Feature nameBus system LON (EF003831)
Feature valueNo
Feature nameMounting method (EF000003)
Feature valueTrunking mounted
Feature nameBus system KNX (EF001499)
Feature valueNo
Feature nameBus system Powernet (EF001501)
Feature valueNo
Feature nameModular expandability (EF006738)
Feature valueNo
Feature nameBus system radio frequency (EF001500)
Feature valueNo
Feature nameWith bus connection (EF001504)
Feature valueYes
Feature nameDifferent phases connectable (EF003905)
Feature valueNo
Feature nameBus system KNX-RF (Radio Frequency) (EF008855)
Feature valueNo
Feature nameMax. number of switching contacts (EF001739)
Feature value1
Feature nameRated operating voltage (EF001435)
Feature value230 V
Feature nameRated current (EF000227)
Feature value2 A
Feature nameSuitable for C-load (EF003832)
Feature valueNo
Feature nameOther bus systems (EF003811)
Feature valueOther
Feature nameLocal operation/hand operation (EF003914)
Feature valueYes
