VCM 5,0/2/15 BLOCK PCB Transformers
VCM 5,0/2/15
BLOCK
PCB Transformers
PCB Transformers VCM 5,0/2/15
PCB transformer, safety isolating transformer, mountable
Home > BLOCK
Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK
Related products
▲Best sellers
▲More info
▲The PCB transformers of the VCM series provide galvanic isolation of the primary circuit from the secondary circuit and are equipped with lugs on the housing for additional mounting options. Thanks to the unique XtraDenseFill resin encapsulation process, the transformers offer permanent corrosion protection, high insulation value, and maximum electrical conductivity.
›Safety isolating transformer according to EN (IEC) 61558-2-6
›Minimal size with high performance
›With dual output coils for series or parallel connection
›Self-extinguishing encapsulation material
| Product | PCB transformer, safety isolating transformer, mountable |
| Order number | VCM 50/2/15 |
| Series | VCM |
| Power | 50 VA |
| Input | 230 V |
| Output | 2 x 15 V • 1.67 Aac |
| Phases | 1 |
| Frequency range | 50 Hz to 60 Hz |
| No-Load Losses | 3.8 W |
| EN Insulation class | B (130°C) |
| UL Insulation class | class 105 |
| Duty Cycle | 100 % |
| Wire material | Copper |
| Efficiency | 87 % |
General
| Short circuit proof | not short-circuit proof |
| Switching group | Iii0 |
| Cooling type | AN |
Environment
| Ambient temperature | -20 °C to 40 °C / -4 °F to 104 °F |
| Max. installation height | 2,000 m / 6,562 ft |
Protection and Safety
| Protection type | IP00 |
| Protection class (prepared) | II |
| Overvoltage category | III |
| Degree of contamination | 1 |
Electrical Connections
| Input terminal | Flat plug connection |
| Output terminal | Flat plug connection |
Size and Weight
| Width | 94 mm / 3.7 in |
| Height | 58.5 mm / 2.3 in |
| Depth | 61 mm / 2.4 in |
| Weight | 1.07 kg / 2.359 lbs |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE BLOCK EN.pdf | 62 Mbytes |
|
| VCM 5,0/2/15 VCM 5,0/2/15 EN_VCM 5,0_2_15.pdf | 339 Kbytes |
|
