PC-0112-150-0 BLOCK Switch Mode Power Supplies
PC-0112-150-0
BLOCK
Switch Mode Power Supplies
Switch Mode Power Supplies PC-0112-150-0
Primary switched mode power supply, single-phase
Home > BLOCK
Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK
Related products
▲Best sellers
▲More info
▲›Stabilised and adjustable output voltage
›Fast tripping of conventional circuit breakers
›DC OK signalling
›Parallel operation
›Push-in terminals
›Robust DIN rail mounting
›Resistant to transient overvoltages up to 4 kV
›3 years warranty
| Product | Primary switched mode power supply, single-phase |
| Order number | PC-0112-150-0 |
| Series | PC 1AC |
Input
| Rated input voltage | 100 Vac to 240 Vac |
| Input voltage range | 85 Vac to 264 Vac |
| Input voltage range | 120 Vdc to 372 Vdc |
| Rated input current (rated load) (100Vac) | 2.07 A |
| Rated input current (rated load) (230Vac) | 0.95 A |
| Internal input fuse | 6.3 AT |
| Switch-on time (100Vac) | 0.71 s |
| Switch-on time (230Vac) | 0.43 s |
| Rated frequency range AC | 44 Hz to 66 Hz |
| Rated frequency range DC | 0 Hz |
| Inrush current limitation NTC < | 30 A |
| Recommended preliminary fuse | 10A, 16A, B/C-Char. |
| Mains failure bridging (rated load) (100Vac) | 28.0 ms |
| Mains failure bridging (rated load) (230Vac) | 28.0 ms |
Output
| Power | 180 W |
| Rated output voltage | 12 Vdc |
| Rated Output Current | 15 A |
| Output voltage range | 11.5 Vdc to 15 Vdc |
| Output Current Limitation (Constant Current) typ. | 16 A |
| Ripple (rated load) typ. | 35 mVss |
| Power factor | 0.91 |
| Max. power loss | 24.7 W |
| Max. feedback resistance | 35 Vdc |
| Verlustleistung Leerlauf (230Vac) | 4.40 W |
| Verlustleistung Nennlast (230Vac) | 21.80 W |
| Überspannungsschutz des Ausgangs | 20.0 Vdc |
| Parallel connection possible | Yes |
| Series connection possible | Yes |
Signaling
| Signal output | Relay contact |
| Status display | Green LED |
Environment
| Ambient temperature | -25 °C to 70 °C / -13 °F to 158 °F |
| Storage temperature | -25 °C to 85 °C / -13 °F to 185 °F |
| Humidity without condensation | 5 % to 96 % |
| Cooling type | natural convection |
| Required minimum distance (side) | 0 mm |
| Required minimum distance (top/bottom) | 50 mm |
Protection and Safety
| Degree of pollution | 2 |
| Protection class according to EN 61140 | III, without PE connection |
Size and Weight
| Width | 55 mm / 2.17 in |
| Height | 127 mm / 5 in |
| Depth | 161 mm / 6.34 in |
| Weight | 1.11 kg / 2.447 lbs |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE BLOCK EN.pdf | 62 Mbytes |
|
| Download general catalog |
|
