HFE 156-230/12 BLOCK EMI Filter
HFE 156-230/12
BLOCK
EMI Filter
EMI Filter HFE 156-230/12
Radio interference suppression filter
electrical stabilizers filters
Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK
Related products
▲Best sellers
▲More info
▲›For general requirements
›Single-stage filter concept
›Efficient filter effect against line-bound interference emissions
›Increase in the interference immunity of the connected consumer
›DIN rail mounting
| Product | Radio interference suppression filter |
| Order number | HFE 156-230/12 |
| Series | HFE 156 |
| Inductance | 5.2 mH |
| Rated current | 12 Aac |
| Rated voltage range | 0 V to 250 V |
| Rated voltage | 230 V |
| Phases | 1 |
| Frequency range | 50 Hz to 60 Hz |
| EN Insulation class | A (105°C) |
| UL Insulation class | class 105 |
| Duty Cycle | 100 % |
| Power loss | 6.20 W |
| Wire material | Copper |
General
| Duty Cycle | 100 % |
| Cooling type | AN |
Environment
| Ambient temperature | -10 °C to 45 °C / 14 °F to 113 °F |
Protection and Safety
| Protection type | IP20 |
| Protection class (prepared) | I |
| Degree of contamination | 2 |
Electrical Connections
| Input terminal | Spring cage terminal |
| Output terminal | Spring cage terminal |
| Terminal PE | Flat plug connection |
Size and Weight
| Width | 45 mm / 1.77 in |
| Height | 110 mm / 4.33 in |
| Depth | 127.5 mm / 5.02 in |
| Weight | 0.55 kg / 1.213 lbs |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOGUE BLOCK EN.pdf | 62 Mbytes |
|
| HFE 156-230/12 HFE 156-230/12 DE_HFE 156-230_1.pdf | 1014 Kbytes |
|
