BLOCK EP 13/6 EP 13/6 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

EP 13/6 BLOCK PCB transformer, safety isolating transformer

Reference: EP 13/6

Manufacturer: BLOCK

Description:

PCB transformer, safety isolating transformer

Categories:

  • BLOCK > transformers

Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK

  • More Info
  • Reviews
Guarantee, repair and return.

* This article may be obsolete. Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

Ask for a quotation and we will check if there are any units available. If not, one of our technicians will look for an alternative solution.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

›Minimum size at high output

›Double output voltage for series or parallel connection

›Very good moisture protection and low noise thanks to vacuum impregnation

›Contact protected on the circuit board thanks to covered solder pin strips

›Stable connection technology with injected round wire soldering pins

›Additional mounting option with holes in the core

ProductPCB transformer, safety isolating transformer
Order numberEP 13/6
SeriesEP
Power13 VA
Input230 V
Output2 x 6 V • 1.08 Aac
Phases1
Frequency range50 Hz to 60 Hz
Short-Circuit Losses4 W
No-Load Losses0.8 W
Short circuit voltage uk19.4 %
EN Insulation classB (130°C)
Duty Cycle100 %
Wire materialCopper
Efficiency73 %
General
Short circuit proofnot short-circuit proof
Switching groupIii0
Cooling typeAN
Environment
Ambient temperature-20 °C to 40 °C / -4 °F to 104 °F
Max. installation height2,000 m / 6,562 ft
Protection and Safety
Protection typeIP00
Protection class (prepared)II
Overvoltage categoryIII
Degree of contamination2
Electrical Connections
Input terminalPin
Output terminalPin
Size and Weight
Width0 mm / 0 in
Height0 mm / 0 in
Depth0 mm / 0 in
Weight0.34 kg / 0.75 lbs
