BLOCK DCT 12-0,5 DCT 12-0,5 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

DCT 12-0,5 BLOCK conventional Power Supply

Reference: DCT 12-0,5

Manufacturer: BLOCK

Description:

conventional Power Supply
conventional Power Supply DCT 12-0,5
Non-stabilized DC power supply

Categories:

  • BLOCK > Sources and Fuses

Brand new product in its original packaging covered by the warranties and certifications provided by BLOCK

  • More Info
  • PDF
  • Reviews
Guarantee, repair and return.

Unit Price: 68,86 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 18-20 weeks.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

The unregulated DC power supplies of the DCT series focus on the core task of voltage and current supply while meeting the requirements for safety isolating transformers according to EN (IEC) 61558-2-6. The robust plastic housing is designed for DIN rail mounting and is ideal for applications such as small distribution boards or meter panels.

›Temperature fuse in the input and a melting fuse in the output

›Separate windings

›Capacitor configuration on the output side

›Permanent corrosion protection, high insulation value, and maximum electrical reliability thanks to XtraDenseFill resin encapsulation

ProductNon-stabilized DC power supply
Order numberDCT 12-0,5
SeriesDCT
Duty Cycle100 %
EN Insulation classB (130°C)
Frequency range50 Hz to 60 Hz
Short-Circuit Losses2.14 W
No-Load Losses1.58 W
Power6 VA
Wire materialCopper
Efficiency61.7 %
General
Short circuit proofconditionally short-circuit proof
Cooling typeAN
Switching groupIi0
Environment
Max. installation height2,000 m / 6,562 ft
Ambient temperature-20 °C to 25 °C / -4 °F to 77 °F
Protection and Safety
Protection typeIP00
Protection class (prepared)II
Degree of contamination2
General
TS35 rail mounting possibleja
Electrical Connections
Output terminalScrew terminal
Input terminalScrew terminal
Size and Weight
Width94 mm / 3.7 in
Height63 mm / 2.48 in
Depth71 mm / 2.8 in
Weight0.433 kg / 0.955 lbs
