2TLA050040R0212 ABB Sense7Z, Actuator, replacement Stainless Steel
2TLA050040R0212
ABB
Sense7Z, Actuator, replacement Stainless Steel
Sense7Z, Stainless Steel Replacement Actuator
Sense7Z Key SS Actuator
Sensors > Magnetic proximity switch
Fences and rolling doors
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| Ordering | |
|---|---|
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 8536500500 |
| Product Main Type | Sense |
| Product Name | Actuator |
| Function | Spare part |
| Status Indicator | No |
| Popular Downloads | |
| Data Sheet, Technical Information | 2TLC010001C0202 |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Marketing Video | 2TLC010018N0201 |
| Installation | |
| Instructions and Manuals | 2TLC172249M0201 |
| Mounting Type | Not flat |
| Dimensions | |
| Product Net Depth / Length | 14 mm |
| Product Net Height | 25 mm |
| Product Net Width | 88 mm |
| Product Net Weight | 0.05 kg |
| CAD Dimensional Drawing | 2CDC001079B0201 |
| Safety Information | |
| Safety Category | 4 |
| Performance Level (PL) | Up to e |
| Safety Integrity Level (SIL) | 3 |
| Technical | |
| Operating Distance (Sn) | 5 mm |
| Suitable For | Sense7Z M12 |
| Sense7Z 2M | |
| Sense7Z 5M | |
| Sense7Z 10M | |
| Technical UL/CSA | |
| Enclosure Type UL/CSA | 1 |
| Environmental | |
| Ambient Air Temperature | Operation -25 ... +70 °C |
| Degree of Protection | IP67 |
| IP69K | |
| Material | Housing: Stainless steel 316 |
| Coating housing: Uncoated | |
| Material Compliance | |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| REACH Declaration | 2CMT2022-006480 |
| RoHS Declaration | 2CMT2022-006499 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Toxic Substances Control Act - TSCA | 2CMT2023-006522 |
| WEEE Category | Product Not in WEEE Scope |
| Certificates and Declarations | |
| cULus Certificate | 2TLC010041D0201 |
| Declaration of Conformity - CE | 2TLC010060D0201 |
| Declaration of Conformity - UKCA | 2TLC010184D0201 |
| TÜV Certificate | 2TLC172125D0201 |
| UL Certificate | 2TLC010041D0201 |
| Container Information | |
| Package Level 1 Units | bag 1 piece |
| Package Level 1 Width | 88 mm |
| Package Level 1 Depth / Length | 25 mm |
| Package Level 1 Height | 14 mm |
| Package Level 1 Gross Weight | 0.05 kg |
| Package Level 1 EAN | 7350024467468 |
| External Classifications and Standards | |
| eClass | V11.0 : 23390192 |
| ETIM 7 | EC002544 - Magnetic proximity switch |
| ETIM 8 | EC002544 - Magnetic proximity switch |
| ETIM 9 | EC002594 - Accessories/spare parts for position switches |
| IDEA Granular Category Code (IGCC) | 3268 >> Switch actuator |
| UNSPSC | 31251516 |
| Object Classification Code | B |
| Feature Name | Feature Value |
|---|---|
| Type of actuation (EF006949) | Magnet |
| Type of electric connection (EF003961) | Other |
| Type of switching output (EF003962) | Other |
| Width sensor (EF007094) | 88 mm |
| Height of sensor (EF007283) | 25 mm |
| Length of sensor (EF007334) | 14 mm |
| Explosion safety category for gas (EF003997) | None |
| Explosion safety category for dust (EF003998) | None |
| Construction type housing (EF004008) | Special construction |
| Housing material (EF001596) | Stainless steel |
| Coating housing (EF001601) | Uncoated |
| Protected switch distance OFF (EF004011) | 10 mm |
| Protected switch distance ON (EF004012) | 20 mm |
| SIL according to IEC 61508 (EF009889) | 3 |
| Performance level according to EN ISO 13849-1 (EF007399) | Level e |
| Ambient temperature (EF002386) | -25 °C |
| Mechanical mounting condition for sensor (EF004041) | Not flat |
| Cross-/short circuit identification possible (EF004093) | Yes |
| Switching distance (EF003647) | 5 mm |
| Suitable for safety functions (EF001597) | Yes |
| With status indication (EF001602) | No |
| Degree of protection (IP) (EF005474) | IP67 |
