PHDX2407 ABB Kit XT2, fixed, horizontal, H200, A800
PHDX2407
ABB
Kit XT2, fixed, horizontal, H200, A800
KIT XT2 PLUG-IN 3/4P HOR H=200 W=800 N1
Switchboards ArTu
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| Technical | |
|---|---|
| Sub-Function 3 | Device Kit |
| Suitable For | Modular boards - System pro E Power |
| Suitable for Product Class | Main Distribution Boards |
| Number of Poles | 34P |
| Version | P; |
| Product Type | 5P5P20P2030 |
| Sub-type | XT2; |
| Remarks | ETIM |
| Design | |
| Material | Pickled steel sheet |
| Material Compliance | |
| RoHS Declaration | 1STE000077 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| RoHS Date | 20231024 |
| REACH Declaration | 1STE000078 |
| REACH Information | False - does not contain substances > 0.1 mass percentage |
| REACH Date | 20241125 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| WEEE Category | Product Not in WEEE Scope |
| WEEE B2C / B2B | Business To Business |
| Environmental | |
| Environmental Information | 1STC803005D0208 |
| 9AKK108467A6707 | |
| Dimensions | |
| Product Net Width | 800 mm |
| Product Net Height | 200 mm |
| Product Net Depth / Length | 800 mm |
| Product Net Weight | 5.2 kg |
| Engineering | |
| Building Information Modeling – BIM | 1STC860077 |
| Ordering | |
| Package Level 1 Units | 1 piece |
| Package Level 1 Gross Weight | 5.2 kg |
| Certificates and Declarations | |
| Declaration of Conformity - CE | 1STC860111 |
| Installation | |
| Instructions and Manuals | 1STM604200R0000 |
| Instructions and Manuals (Part 2) | 1SDC007110G0902 |
| Popular Downloads | |
| Data Sheet, Technical Information | 1STC803005D0208 |
| External Classifications and Standards | |
| ETIM 9 | EC002620 - Components for installation (enclosure/cabinet) |
| ETIM 10 | EC002620 - Components for installation (enclosure/cabinet) |
| eClass | V11.1 : 27182811 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG ABB ARTU EN.pdf | 21 Mbytes |
|
| PHDX2407 PHDX2407 EN_PHDX2407.pdf | 74 Kbytes |
|
