2TLA920502R0003 ABB HD5-B-101 3-position knob

Reference: 2TLA920502R0003

Manufacturer: ABB

Description:

HD5-B-101 3-position knob
HD5-B-101 3-position controller
Three position device with AS-i Integrated technology. With Emergency stop button & 1 front + 2 top auxiliary buttons. Home position sensor and flashlight. M12-5 male connector.HD5 is suitable for Food and Beverage applications with the following features: Resistant to most chemicals, fiberglass reinforced plastic, anti-condensation membrane, IP65.

Categories:

  • Sensors > Agreement switch
  • ABB > Fences and rolling doors

Brand new product in its original packaging covered by the warranties and certifications provided by ABB

  • More Info
  • Reviews
Guarantee, repair and return.

Unit Price: 1.028,08 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 25 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

MORE INFO

b'

General Information

Extended Product Type:
HD5-B-101
Product ID:
2TLA920502R0003
EAN:
4013614554018
Catalog Description:
HD5-B-101 Three-position device AS-i
Long Description:
Three position device with AS-i Integrated technology. With Emergency stop button & 1 front + 2 top auxiliary buttons. Home position sensor and flashlight. M12-5 male connector.HD5 is suitable for Food and Beverage applications with the following features: Resistant to most chemicals, fiberglass reinforced plastic, anti-condensation membrane, IP65.
\n

Additional Information

Product Name:
Three-position handheld device - Complete
Function:
Three-position device used to allow a limited movement of the machine when the operator is in the dangerous area. Developed for the Food and Beverage industry.
Sub-Function:
1 front and 2 top auxiliary buttons
Sub-Function 2:
Flashlight

Home position sensor
Special Functions:
Emergency Stop Button
Status Indicator:
Yes
Application:
Suitable for Food and Beverage

Safety Information

Certification Agency:
TÜV, cULus
Performance Level (PL):
Up to e
B10d Value:
2 million operations to middle position

968 000 operations to bottom position

Technical

Communication Interface:
AS-i
Connection Configuration:
M12-5 male
Number of Contacts CO:
2
Number of Contacts NC:
0
Number of Contacts NO:
0
Rated Operational Current DC-12 (Ie):
(24 V) 0.02 A

Environmental

Degree of Protection:
IP65

Technical UL/CSA

Enclosure Type UL/CSA:
1

Popular Downloads

Data Sheet, Technical Information:\n2TLC010093L0201
Instructions and Manuals:\n2CDC172107D0201
Dimension Diagram:\n2CDC172110D0201

Certificates and Declarations (Document Number)

cULus Certificate:\n2TLC010050D0201
Declaration of Conformity - CE:\n2TLC010045D0201
Instructions and Manuals:\n2CDC172107D0201

Dimensions

Product Net Width:
55 mm
Product Net Depth / Length:
75 mm
Product Net Height:
185 mm
Product Net Weight:
0.26 kg

Ordering

Minimum Order Quantity:
1 piece
Country of Origin:
Germany (DE)
Customs Tariff Number:
85365019

Classifications

Object Classification Code:
X
ETIM 6:
EC002571 - Agreement switch
ETIM 7:
EC002571 - Agreement switch
UNSPSC:
39122221
