ABBElectronic relays1SVR405651R6010 ABB standard base for 2 contacts Push-in
ABB 1SVR405651R6010 1SVR405651R6010 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

1SVR405651R6010 ABB standard base for 2 contacts Push-in

Reference: 1SVR405651R6010

Manufacturer: ABB

Description:

standard base for 2 contacts Push-in
CR-M2LP Push-in socket for 2c/o CR-M relay

Categories:

  • Relays > Relay socket
  • ABB > Electronic relays

Brand new product in its original packaging covered by the warranties and certifications provided by ABB

  • More Info
  • ETIM
  • PDF
  • Reviews
Guarantee, repair and return.

Total: 43,95 €

Unit Price: 4,395 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 25 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Ordering
EAN4053546062137
Minimum Order Quantity10 piece
Customs Tariff Number85366990
Popular Downloads
Data Sheet, Technical Information2CDC110004C0210_05
Instructions and Manuals1SVC405650M9040
CAD Dimensional Drawing2CDC001079B0201
Dimensions
Product Net Width30.6 mm
Product Net Height42.5 mm
Product Net Depth / Length98.4 mm
Product Net Weight0.057 kg
Technical
FunctionAccessory for interface relays CR-M
Sub-FunctionSocket for miniature relays
Sub-Function 2Logical socket for miniature relay 2 c/o or 4 c/o
Rated Operational Voltage250 V
Output Signal250 V / 10 A
Terminal TypePush-in Spring Terminals
Rated Insulation Voltage (Ui)2000 V
Wire Stripping Length10 mm
Recommended Screw Driver2.5
Mounting Position1
StandardsCAN/CSA C22.2 No.14
IEC/EN 63000
IEC/EN 61984
UL 508
Technical UL/CSA
Connecting Capacity Main Circuit UL/CSAFlexible with Ferrule 2x 20-17 AWG
Rigid 2x 20-16 AWG
Stranded 2 x 20-16 AWG
Flammability According to UL94V-0
Environmental
Ambient Air TemperatureOperation -40 ... +70 °C
Storage -40 ... +70 °C
Maximum Operating Altitude Permissible2000 m
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SVD981001-4501
RoHS Declaration1SVD981001-4401
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006536
Certificates and Declarations
CSA CertificateCSA_262671_2785566
cURus CertificatecURus508_E244328
Declaration of Conformity - CE1SVD982020-0001
Declaration of Conformity - UKCA1SVD982020-1000
Container Information
Package Level 1 Unitscarton 10 piece
Package Level 1 Width104 mm
Package Level 1 Depth / Length162 mm
Package Level 1 Height87 mm
Package Level 1 Gross Weight0.624 kg
Package Level 1 EAN4053546062144
External Classifications and Standards
Object Classification CodeK
ETIM 7EC001456 - Relay socket
ETIM 8EC001456 - Relay socket
ETIM 9EC001456 - Relay socket
eClassV11.0 : 27371603
UNSPSC39122335
E-Number (Norway)4187815

ETIM for 1SVR405651R6010 Relays (EC001456)

Feature nameType of electric connection (EF003961)
Feature valueSpring clamp connection
Feature nameMounting method (EF000003)
Feature valueDIN rail (top hat rail) 35 mm
Feature nameWith detachable clamps (EF003340)
Feature valueNo
Feature nameFunction extension possible (EF003444)
Feature valueNo
Feature nameNumber of pins (EF005580)
Feature value0
Feature nameWidth (EF000008)
Feature value30.6 mm
Feature nameHeight (EF000040)
Feature value42.5 mm
Feature nameDepth (EF000049)
Feature value98.4 mm
