1SDA100601R1 ABB Ekip Touch Measuring LSI In 630 XT5 3p
1SDA100601R1
ABB
Ekip Touch Measuring LSI In=630 XT5 3p
Low-voltage industrial components > Shunt release (for power circuit breaker)
Molded case "Isomax-Tmax"
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 642b6bd2-21b4-4bf1-977f-e76154c906a6 Italy |
| Simplified SCIP | b494bb51-e434-493e-af03-1ffb98a7955a Belgium |
| 9eacb37d-5ce1-43e3-b4cb-b4375dfd064c Hungary | |
| b9badee3-8218-4a69-a85b-354e715f7138 Sweden | |
| 7a120358-b3bc-4d69-9696-0cf16ca5c363 Norway | |
| cae264e4-ca38-485e-a92c-33382b4ebf0c Poland | |
| 9c03eda1-460d-4615-a5c1-c47cf52356c1 Germany | |
| 774d47f4-795b-4903-845f-7f5721f1f37a France | |
| 6127aeb6-30bf-4863-aa78-03bbb5634643 France | |
| 2ce11fd0-a398-4587-8a31-d3b96fb3b82f Spain | |
| eabefe29-1a13-499b-9a63-eabf4d07c810 Poland | |
| cd833f30-8cb4-4b4c-90cd-c9856f4080cc Netherlands | |
| d5e0340b-ebe7-430a-896e-b976e26263b8 Poland | |
| 868eb31d-0139-482b-871e-749a523a7782 Germany | |
| ca874e7c-3ab4-4473-97c1-97a161f9de76 Sweden | |
| 111abdca-f2b8-40d9-9886-b97278a20c6e Bulgaria | |
| 037bc1a2-d742-4634-a290-da3bce10098b Germany | |
| 3a61e13c-1832-40e9-9be4-1131560b886d Portugal | |
| fe217cc2-071f-4f27-af9a-8b619a52cf1d Greece | |
| 7e980fd6-71c8-4e2d-81fc-100243b3679c Croatia | |
| dc854124-553a-447d-9192-2654c6ec09d3 Czech Republic | |
| 5aba17cb-6bf6-43b7-bdfc-ab00e7765cb3 Denmark | |
| b9aa89a3-b6a2-4bf7-9b68-e5762dcc34b1 Germany | |
| 0ab5e72a-d67f-45e6-b8bc-5440bef222f9 Belgium | |
| c7f0b4c2-da3f-4105-b041-8b1b5370e679 Finland | |
| bec9180e-8ab2-4086-8347-3857208be227 Germany | |
| Environmental | |
| Ambient Air Temperature | Operation -40 ... 125 °C |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| E-Number (Finland) | 3641576 |
| E-Number (Norway) | 4380346 |
| EAN | 8056221006774 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Dimensions | |
| Product Net Weight | 1.395 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 120 mm |
| Package Level 1 Height | 180 mm |
| Package Level 1 Depth / Length | 225 mm |
| Package Level 1 Gross Weight | 1.559 kg |
| Package Level 1 EAN | 8056221006774 |
| Additional Information | |
| Circuit Breaker Type to be Associated | Power Distribution |
| Product Main Type | Accessories for Tmax XT |
| Product Name | Accessory |
| Product Type | Accessory |
| Suitable For | XT5 |
| Technical | |
| Configuration Type | Loose or configurable |
| Current Type | AC |
| Number of Poles | 3P |
| Order Multiple | 1 piece |
| Rated Current (In) | 630 A |
| Release | Ekip Touch Measuring LSI |
| Release Type | EL |
| Standards | IEC60947-2 |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | Refer to the EU Declaration of the relative Circuit Breaker |
| EU Data Act Compliance Declaration | 1SDH002560A1001 |
| Instructions and Manuals | 1SDH002039A1002 |
| External Classifications and Standards | |
| ETIM 9 | EC001023 - Shunt release (for power circuit breaker) |
| ETIM 10 | EC001023 - Shunt release (for power circuit breaker) |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370418 |
| Feature Name | Feature Value |
|---|---|
| Type of electric connection (EF003961) | Other |
| Number of contacts as normally open contact (EF008256) | 0 |
| Number of contacts as normally closed contact (EF008255) | 0 |
| Number of contacts as change-over contact (EF008257) | 0 |
| Suitable for power circuit breaker (EF005863) | Yes |
| Suitable for off-load switch (EF001543) | No |
| Suitable for motor safety switch (EF005826) | No |
| Suitable for overload relay (EF001545) | Yes |
