1SDA100261R1 ABB XT4V 160 INTERRUPT PART 3p F F
1SDA100261R1
ABB
XT4V 160 INTERRUPT PART 3p F F
XT4V 160 BREAKING PART 3p F F
Low-voltage industrial components > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| Circular Value | |
| Circular Design Principles Recyclability Rate | Design for Closing Resource Loops - Standard EN45555 - 56.30 % |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| End of Life Instructions | 9AKK108468A2351 |
| Group Waste to Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| Eco Transparency | |
| Environmental Product Declaration - EPD | 9AKK108469A1857 |
| 9AKK108468A1892 | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Information | 9AKK108466A1424 |
| RoHS Status | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| SCIP | cd53ac7b-fb27-4cd5-bbfd-d93be1d57bf5 Italy (IT) |
| Simplified SCIP | 6c434b54-0713-4bd7-822f-1a1a5e2ac9c1 Germany (DE) |
| cf94df9b-bece-415e-8d41-448b6ce41663 Netherlands (NL) | |
| 798b9105-18b1-4b21-aefe-87a2290ca374 Estonia (EE) | |
| 90fef06b-66fd-4716-b538-22caf3644a73 Greece (GR) | |
| 017b6d4a-36ad-4ff1-aa22-f78d91cd5df4 Portugal (PT) | |
| f33e474c-b2a8-4a06-8c42-ac78ad63b162 Bulgaria (BG) | |
| 3abcce60-a306-4e03-a07a-7494f351f364 Sweden (SE) | |
| 4bcf911a-4073-425f-9c78-c1395acbbac0 Poland (PL) | |
| aa5b204e-c0de-45ba-8105-ff5c9d2336c7 France (FR) | |
| 438e8f84-d83f-4aac-a5f6-f775fd7eb509 Sweden (SE) | |
| d2e8f054-51df-4c14-a8d3-0897b05c7ab1 Germany (DE) | |
| 7e0a6d40-9fe9-4102-b9d4-65393430fd6d Germany (DE) | |
| e7691435-19a7-40b7-a5cd-6263c8241432 France (FR) | |
| 41d94e56-13da-4497-9c25-36b58edd5d82 Netherlands (NL) | |
| fd77a899-5246-43d2-9135-176fbfb75d78 Spain (ES) | |
| a70be5e5-022a-47a6-bf32-c69ee332144d Netherlands (NL) | |
| cc608d74-f040-41ad-aa13-b829bff484b1 Norway (NO) | |
| db816a06-7f4a-441a-a7b3-4f0c76498f40 Finland (FI) | |
| df9a786f-dad5-41ac-8525-0684a3c41dc7 Netherlands (NL) | |
| d761fc59-cc66-4244-862a-100446bb3c49 Germany (DE) | |
| b56c3885-80c8-4965-aa4f-0bc5ef35ffbc Denmark (DK) | |
| e1390365-9982-4988-950b-3b3e996d977e Poland (PL) | |
| 534dedd3-9204-4fa5-bb33-f3ef3a03a2c5 Germany (DE) | |
| fb4b82d4-660e-4e08-be48-be25d9b7a766 Croatia (HR) | |
| e0347387-9704-4a11-b71e-7ad3592eda81 Czech Republic (CZ) | |
| b7b4b8b7-9659-4d32-8351-66346fb5221c Poland (PL) | |
| d3dc7c94-7dcf-42f1-bc80-bab6669c377a Netherlands (NL) | |
| Ordering | |
| E-Number (Finland) | 3641115 |
| EAN | 8056221003155 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85389099 |
| Dimensions | |
| Product Net Width | 105 mm |
| Product Net Height | 160 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 1.6 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 305 mm |
| Package Level 1 Height | 285 mm |
| Package Level 1 Depth / Length | 370 mm |
| Package Level 1 Gross Weight | 2 kg |
| Package Level 1 EAN | 8056221003155 |
| Additional Information | |
| Electrical Durability | 120 cycles per hour |
| 10000 cycle | |
| Mechanical Durability | 240 cycles per hour |
| 25000 cycle | |
| Number of Poles | 3 |
| Order Multiple | 1 piece |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Breaking Part |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 750 V DC | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 200 kA |
| (230 V AC) 200 kA | |
| (240 V AC) 200 kA | |
| (380 V AC) 150 kA | |
| (415 V AC) 150 kA | |
| (440 V AC) 150 kA | |
| (500 V AC) 85 kA | |
| (525 V AC) 70 kA | |
| (690 V AC) 50 kA | |
| (250 V DC) 2 Poles in Series 100 kA | |
| (500 V DC) 2 Poles in Series 100 kA | |
| (500 V DC) 3 Poles in Series 100 kA | |
| (750 V DC) 3 Poles in Series 50 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 200 kA |
| (230 V AC) 200 kA | |
| (240 V AC) 200 kA | |
| (380 V AC) 150 kA | |
| (415 V AC) 150 kA | |
| (440 V AC) 150 kA | |
| (500 V AC) 85 kA | |
| (525 V AC) 70 kA | |
| (690 V AC) 50 kA | |
| (250 V DC) 2 Poles in Series 100 kA | |
| (500 V DC) 2 Poles in Series 100 kA | |
| (500 V DC) 3 Poles in Series 100 kA | |
| (750 V DC) 3 Poles in Series 50 kA | |
| Rated Uninterrupted Current (Iu) | 160 A |
| Short-Circuit Performance Level | V |
| Standards | IEC60947-2 |
| Sub-type | XT4 |
| Terminal Connection Type | Front |
| Version | F |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK106713A5529 |
| Instructions and Manuals | 1SDH000722R0001 |
| Classifications | |
| ETIM 7 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 8 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MOLDED CASE ISOMAX-TMAX 2024 EN.pdf | 71 Mbytes |
|
