1SDA100226R1
ABB
1
C.BREAKER TMAX XT4S 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP DIP LIG R 40 A
Molded Case Circuit Breakers ≤ 250 A Xtmax
* Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
b'
XT4S 160 Ekip Dip LIG In=40A 4p F F
1SDA100226R1
8056221002806
XT4S 160 Ekip Dip LIG In=40A 4p F F
C.BREAKER TMAX XT4S 160 FIXED FOUR-POLE WITH FRONT TERMINALS AND SOLID-STATE RELEASE IN AC EKIP DIP LIG R 40 A
8056221002806
1 piece
85362090
140 mm
160 mm
82.5 mm
3.05 kg
1 piece
145 mm
210 mm
168 mm
3.5 kg
8056221002806
Power Distribution
AC
120 cycles per hour
8000 cycle
240 cycles per hour
25000 cycle
4
1 piece
at Rated Operating Conditions per Pole 0.6 W
SACE Tmax XT
Moulded Case Circuit Breaker
CB
40 A
8 kV
1000 V
690 V AC
(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 36 kA
(525 V AC) 25 kA
(690 V AC) 12 kA
(220 V AC) 85 kA
(230 V AC) 85 kA
(240 V AC) 85 kA
(380 V AC) 50 kA
(415 V AC) 50 kA
(440 V AC) 50 kA
(500 V AC) 36 kA
(525 V AC) 25 kA
(690 V AC) 12 kA
160 A
Ekip Dip LIG
EL
S
IEC 60947
XT4
Fixed Circuit-Breakers
F
EC000228 - Power circuit-breaker for trafo/generator/installation prot.
EC000228 - Power circuit-breaker for trafo/generator/installation protection
Q
5. Small Equipment (No External Dimension More Than 50 cm)
Title: | Size: | Type: |
---|---|---|
PDF CATALOG MOLDED CASE ISOMAX-TMAX EN.pdf | 25 Mbytes | |
1SDA100226R1 1SDA100226R1 EN_1SDA100226R1.pdf | 140 Kbytes |
