1SDA068180R1 ABB XT4H250 PART 4P F F INTERRUPTION
1SDA068180R1
ABB
XT4H250 PART 4P F F INTERRUPTION
XT4H 250 BREAKING PART 4p F F
Low-voltage industrial components > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2351 |
| Environmental Product Declaration - EPD | 9AKK108469A1857 |
| 9AKK108468A1892 | |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 56.30 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | 5c319188-d820-4a28-b655-b0e0e52761fa Italy |
| Simplified SCIP | e0d4b978-37a5-41a6-8493-21116cb519e2 Poland |
| 87797410-38e8-4ddc-ae85-8bc564debae2 Poland | |
| 543000b5-bd6b-4c86-b239-e55153f94863 Germany | |
| 9b64b075-4725-4afe-a904-45488f6f1994 Germany | |
| f8902870-7774-4283-a477-8bda24c0bc3b Croatia | |
| d4575fd8-5fdd-4170-b906-02a4b67380a0 France | |
| d2b46837-8c39-4728-80ef-4faaec59fbc7 Czech Republic | |
| 5d8e3587-a97a-471a-a739-1923ab9c2813 Germany | |
| a6954f45-272a-4fae-b8a7-30994cdcb1b7 Poland | |
| cfe29310-453b-4943-9a89-96782a437988 Estonia | |
| bf4f99f2-dbe7-4181-b180-b4dd05ed5516 Spain | |
| 572a8491-9fd9-46ae-be9b-6f945967441e Belgium | |
| 99ac7ac7-456c-42dc-837f-0da71110f4e7 Hungary | |
| ddc02244-cee1-4de5-99bb-c02296d00ed0 Sweden | |
| 6a4f5172-0d4c-4401-b850-bf4868705e06 Denmark | |
| d7ecf7ce-663e-467a-9cb1-0ab5d938e695 Belgium | |
| bc93d0af-91d7-4ec2-bdea-01c10783aac4 Finland | |
| b21dfee4-674b-4ed3-be6a-9dbf79eae0cb Hungary | |
| a8ddbc3c-4f3c-4e77-9d9c-6330b8c9338c France | |
| 26cfe2a1-c8f5-42dd-8494-f27f34f0337f Portugal | |
| 4bbb1225-e798-447d-9594-1b0dcc52524d Germany | |
| af5b7f90-0d8d-4f7e-b043-ff0c9f595aec Greece | |
| 50ef131d-9597-4293-9062-f996953ffb35 Germany | |
| 3a441056-8f9e-40df-b985-faeec4b7c469 Norway | |
| bdfa113d-eb57-4e67-9de2-c294690516db Sweden | |
| a253434b-0e3d-4170-9b71-c49e007da0c8 Netherlands | |
| e7b89896-f1f4-4a84-8d23-39907a0c2d70 Bulgaria | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| E-Number (Finland) | 3641100 |
| E-Number (Norway) | 4380186 |
| EAN | 8015644696214 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 140 mm |
| Product Net Height | 160 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 2.65 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 171 mm |
| Package Level 1 Height | 215 mm |
| Package Level 1 Depth / Length | 151 mm |
| Package Level 1 Gross Weight | 3.1 kg |
| Package Level 1 EAN | 8015644696214 |
| Additional Information | |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Breaking Part |
| Version | F |
| Technical | |
| Electrical Durability | 120 cycles per hour |
| 8000 cycle | |
| Mechanical Durability | 240 cycles per hour |
| 25000 cycle | |
| Number of Poles | 4P |
| Opening Time | CB with SOR 30 ms |
| CB with UVR 30 ms | |
| Order Multiple | 1 piece |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 45 kA | |
| (690 V AC) 15 kA | |
| (250 V DC) 2 Poles in Series 70 kA | |
| (500 V DC) 2 Poles in Series 70 kA | |
| (500 V DC) 3 Poles in Series 70 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 100 kA |
| (230 V AC) 100 kA | |
| (240 V AC) 100 kA | |
| (380 V AC) 70 kA | |
| (415 V AC) 70 kA | |
| (440 V AC) 65 kA | |
| (500 V AC) 50 kA | |
| (525 V AC) 45 kA | |
| (690 V AC) 15 kA | |
| (250 V DC) 2 Poles in Series 70 kA | |
| (500 V DC) 2 Poles in Series 70 kA | |
| (500 V DC) 3 Poles in Series 70 kA | |
| Rated Uninterrupted Current (Iu) | 250 A |
| Rated Voltage (Ur) | 690 V |
| Short-Circuit Performance Level | H |
| Standards | IEC60947-2 |
| Sub-type | XT4 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK106713A5529 |
| GL Certificate | 1SDL000163R0095 |
| LR Certificate | 1SDL000163R0100 |
| Instructions and Manuals | 1SDH000722R0001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MOLDED CASE ISOMAX-TMAX 2024 EN.pdf | 71 Mbytes |
|
