1SDA068179R1 ABB XT4S250 PART OF 4P F INTERRUPTION
1SDA068179R1
ABB
XT4S250 PART OF 4P F INTERRUPTION
XT4S 250 BREAKING PART 4p F F
Low-voltage industrial components > Power circuit-breaker for trafo/generator/installation protection
Molded Case Circuit Breakers ≤ 250 A Xtmax
Brand new product in its original packaging covered by the warranties and certifications provided by ABB
Best sellers
▲More info
▲| ABB EcoSolutions | |
|---|---|
| ABB EcoSolutions | Yes |
| ABB Site Meeting Group Waste To Landfill Target | UL 2799 Zero Waste To Landfill Validation available |
| End Of Life Disassembling Instructions | 9AKK108468A2351 |
| Environmental Product Declaration - EPD | 9AKK108469A1857 |
| 9AKK108468A1892 | |
| Recyclability Rate of the Product acc. to EN45555 | Design for Closing Resource Loops - Standard EN45555 - 56.30 % |
| Material Compliance | |
| REACH Declaration | 9AKK108466A1425 |
| RoHS Declaration | 9AKK108466A1424 |
| RoHS Information | Following EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019 |
| Conflict Minerals Reporting Template (CMRT) | 9AKK108467A5658 |
| Toxic Substances Control Act - TSCA | 9AKK108467A8326 |
| SCIP | c450a3df-5ce5-4597-94e9-53a9e6a84bd7 Italy |
| Simplified SCIP | 257bd314-7a59-4e51-ac6a-cb4464ada487 Bulgaria |
| f93d8e90-2e1f-4e02-8aaa-cfb82b750fd2 Netherlands | |
| db8fced5-c40b-4b87-a921-f2da84388f65 Norway | |
| f5b47456-ea3e-45cc-b94d-6a86e8d8ccc3 Sweden | |
| 89433a7e-fcd2-4cc0-b3c3-7cdee1b304a9 Germany | |
| e4fd21ae-7ecd-4145-92aa-72bba750c4b8 France | |
| a1459492-97f4-4be4-90e5-7df74da8d0dc Greece | |
| dd9be6c4-6063-4c81-a65f-cf03eaa4eb9f Belgium | |
| 1e32c8dd-3bf1-4e50-8104-b98ba38f10a3 Hungary | |
| 48baed2e-9f4b-4baa-be0a-2b6e0c73b39c Finland | |
| be5717d2-0ca9-443a-b18e-0524dd6f3851 Poland | |
| d36b8fb2-3dfb-4fed-a5d0-9522bfe625d9 Estonia | |
| 1d04ff7e-92fb-49a3-92eb-93fc9fb74258 Germany | |
| d83af3b5-b83e-4f56-ad91-b201136be220 Croatia | |
| e2ab3936-4675-47ac-bb27-b307a4e2b19e Poland | |
| 10041f1b-1b3e-42d6-acc9-810e4663f10c Poland | |
| dba81a66-e026-46e4-9dac-fa5fc13537d3 Hungary | |
| 6a0f5c9b-fff0-4d6d-ae95-ebfb553619cc Belgium | |
| 275f6df1-bcf2-484b-9ad3-d5fa1b5327f7 Spain | |
| e06e0a85-5bf0-4494-84aa-85333c8f75ab Germany | |
| 765629b1-41d8-4e87-9c67-6e364683ef26 Czech Republic | |
| 253bf7c5-5daf-4bb4-9d28-1071a176bddf Germany | |
| 89bc9058-1d66-43f2-85dd-708631ed5991 France | |
| f3ea7f8b-caae-4846-ba4e-5a182d6eb2c4 Germany | |
| 62f4363f-5a83-4878-98af-5f752c9b8c8e Sweden | |
| 155df062-1c69-458b-8910-dd6d1c76ef29 Denmark | |
| c5ecd498-e0e9-48d9-a6b5-55fbc851db00 Portugal | |
| Environmental | |
| Environmental Information | 9AKK108467A6707 |
| Ordering | |
| E-Number (Finland) | 3641076 |
| E-Number (Norway) | 4380185 |
| EAN | 8015644020767 |
| Minimum Order Quantity | 1 piece |
| Customs Tariff Number | 85362090 |
| Dimensions | |
| Product Net Width | 140 mm |
| Product Net Height | 160 mm |
| Product Net Depth / Length | 82.5 mm |
| Product Net Weight | 2.65 kg |
| Container Information | |
| Package Level 1 Units | box 1 piece |
| Package Level 1 Width | 171 mm |
| Package Level 1 Height | 215 mm |
| Package Level 1 Depth / Length | 151 mm |
| Package Level 1 Gross Weight | 3.1 kg |
| Package Level 1 EAN | 8015644020767 |
| Additional Information | |
| Product Main Type | SACE Tmax XT |
| Product Name | Moulded Case Circuit Breaker |
| Product Type | Breaking Part |
| Version | F |
| Technical | |
| Electrical Durability | 120 cycles per hour |
| 8000 cycle | |
| Mechanical Durability | 240 cycles per hour |
| 25000 cycle | |
| Number of Poles | 4P |
| Opening Time | CB with SOR 30 ms |
| CB with UVR 30 ms | |
| Order Multiple | 1 piece |
| Rated Frequency (f) | 50 / 60 Hz |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Insulation Voltage (Ui) | 1000 V |
| Rated Operational Voltage | 690 V AC |
| 500 V DC | |
| Rated Service Short-Circuit Breaking Capacity (Ics) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 36 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 12 kA | |
| (250 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 3 Poles in Series 50 kA | |
| Rated Ultimate Short-Circuit Breaking Capacity (Icu) | (220 V AC) 85 kA |
| (230 V AC) 85 kA | |
| (240 V AC) 85 kA | |
| (380 V AC) 50 kA | |
| (415 V AC) 50 kA | |
| (440 V AC) 50 kA | |
| (500 V AC) 36 kA | |
| (525 V AC) 25 kA | |
| (690 V AC) 12 kA | |
| (250 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 2 Poles in Series 50 kA | |
| (500 V DC) 3 Poles in Series 50 kA | |
| Rated Uninterrupted Current (Iu) | 250 A |
| Rated Voltage (Ur) | 690 V |
| Short-Circuit Performance Level | S |
| Standards | IEC60947-2 |
| Sub-type | XT4 |
| Terminal Connection Type | Front |
| Certificates and Declarations | |
| Data Sheet, Technical Information | 1SDC210100D0206 |
| 1SDC210099D0206 | |
| Declaration of Conformity - CE | 9AKK106713A5529 |
| GL Certificate | 1SDL000163R0095 |
| LR Certificate | 1SDL000163R0100 |
| Instructions and Manuals | 1SDH000722R0001 |
| External Classifications and Standards | |
| ETIM 9 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| ETIM 10 | EC000228 - Power circuit-breaker for trafo/generator/installation protection |
| Object Classification Code | Q |
| UNSPSC | 39120000 |
| WEEE Category | 5. Small Equipment (No External Dimension More Than 50 cm) |
| eClass | V11.1 : 27370409 |
Datasheet - PDF
▲| Title: | Size: | Type: |
|---|---|---|
| PDF CATALOG MOLDED CASE ISOMAX-TMAX 2024 EN.pdf | 71 Mbytes |
|
