ABB 1SCA123675R1001 1SCA123675R1001 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

1SCA123675R1001 ABB Disconnector switch OT200E03P31 +JCI

Reference: 1SCA123675R1001

Manufacturer: ABB

Description:

Disconnector switch OT200E03P31 +JCI
OT200E03P31 SWITCH-DISCONNECTOR

Categories:

  • Low-voltage industrial components > Switch disconnector
  • ABB > Manual Switches

Brand new product in its original packaging covered by the warranties and certifications provided by ABB

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

Unit Price: 189,75 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 25 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

ABB EcoSolutions
End Of Life Disassembling Instructions1SCC301117M0201
Environmental Information1SCC301265D0201
Environmental Product Declaration - EPD1SCC301282D0201
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration1SCC011021D0201
RoHS Declaration1SCC011020D0201
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
SCIP18ab7a98-6ffe-4766-be8f-70f50834dbbc Finland
Simplified SCIPd5d6b716-e602-4eea-ba83-6ea0811d88be Germany
a9b99c08-35ec-4ad5-b052-b0536c1ce72e Greece
964c9267-b80c-4cb4-abd5-6337a42611da Portugal
cfe1605c-490b-45de-9b7c-1cc21bc6a7c7 Estonia
ecf50abc-fb2d-46ac-b51b-bfb72d48952b Denmark
fcb9c2a9-0ab7-4f42-89a2-547105e63497 Poland
5f559094-95f8-4708-ac7a-ac1030cc4448 Germany
542c7974-94e6-448e-ad1e-457f5358201a Germany
afd53f8d-a2fb-48fe-89f7-0d70c5f0fb2a Czech Republic
1cd4e068-5ce1-49dc-9d07-bc9b0c822f0f Poland
5604b7dd-0031-433f-a702-0f09e3a8e39e Hungary
b7a49f08-b921-4640-9337-4d69ee674e01 France
d4c98037-ab65-4b0e-8203-91e491d2de88 Croatia
6b8f3e3a-dd48-4be7-bf0e-9400631c7c6e Sweden
78ceea60-bf39-4b7b-985f-2ae4b71bd3ee France
37c4ad15-7036-470a-abec-97c8b17dc2d0 Belgium
ce795e26-4daf-47fb-8051-260568caf92c Italy
cf734ae4-9612-41a0-8e70-5747f9ff4d07 Germany
2cf3f001-e4be-486f-8702-8e33afa72e58 Netherlands
cf43b81e-98f9-4fc6-b272-349fe17bc5c0 Hungary
b81c3766-7a90-4239-8b29-065ca31d2d73 Bulgaria
729f6443-d6e5-477d-b14e-a28c1581c45b Sweden
40e5018b-aff4-4ce2-bd98-04b304d446db Spain
b2461925-aeba-4d72-a7d5-8a5c82dec935 Belgium
8c84266f-0197-471c-83c4-12cb65615228 Norway
07d19605-9653-4408-b6bf-2950e8619987 Poland
e2282e4d-16de-4c7d-9d86-fdfc34c49540 Germany
Toxic Substances Control Act - TSCA1SCC011025D0201
Popular Downloads
Data Sheet, Technical InformationNo documentation needed
Instructions and Manuals1SCC301031M0220
Mechanical Drawings1SCC307633F0001
1SCC307632F0001
OT200-250E03.stp
OT200-250E03.igs
Environmental Product Declaration - EPD1SCC301282D0201
Environmental
Degree of ProtectionFront IP00
Environmental Information1SCC301265D0201
Pollution Degree3
Ordering
Minimum Order Quantity1 piece
Customs Tariff Number85365080
Country or Territory of OriginFinland
Dimensions
Product Net Width145.5 mm
Product Net Height150 mm
Product Net Depth / Length82.5 mm
Product Net Weight1.6 kg
Container Information
Package Level 1 Unitsbox 1 piece
Package Level 1 Width170 mm
6.7 in
Package Level 1 Depth / Length190 mm
7.5 in
Package Level 1 Height145 mm
5.7 in
Package Level 1 Gross Weight1.7 kg
3.8 lb
Package Level 1 EAN6417019544359
Technical
Conventional Thermal Current (Ithe)Fully Enclosed 200 A
Degree of ProtectionFront IP00
Handle ColorBlack
Handle TypeHandle and shaft included
Mechanical Durability20000
Number of Poles3P
Pollution Degree3
Power Lossat Rated Operating Conditions per Pole 4.0 W
Rated Impulse Withstand Voltage (Uimp)12 kV
Rated Insulation Voltage (Ui)acc. to IEC/EN 60664-1 1000 V
Rated Operational Current AC-21A (Ie)(380 ... 415 V) 200 A
(500 V) 200 A
(690 V) 200 A
Rated Operational Current AC-22A (Ie)(380 ... 415 V) 200 A
(500 V) 200 A
(690 V) 200 A
Rated Operational Current AC-23A (Ie)(380 ... 415 V) 200 A
(500 V) 200 A
(690 V) 200 A
Rated Operational Power AC-23A (Pe)(220 ... 240 V) 60 kW
(400 ... 415 V) 110 kW
(500 V) 132 kW
(690 V) 200 kW
Rated Operational VoltageMain Circuit 1000 V
Rated Short-Circuit Making Capacity (Icm)(690 V) 30 kA
Rated Short-time Withstand Current Low Voltage (Icw)for 1 s 8 kA
StandardsIEC 60947-3
Terminal TypeLug terminals
Tightening Torqueacc. IEC 60947-1 15 … 22 N·m
Technical UL/CSA
Tightening Torqueacc. IEC 60947-1 15 … 22 N·m
Certificates and Declarations
A2L Certificate – IEC1SCC301337D0201
Declaration of Conformity - CE1SCC301131D2705
External Classifications and Standards
Object Classification CodeQ
ETIM 9EC000216 - Switch disconnector (low voltage)
ETIM 10EC000216 - Switch disconnector (AC)
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)

ETIM for 1SCA123675R1001 Low-voltage industrial controls and switchgear (EC000216)

Feature nameVersion as main switch (EF006981)
Feature valueYes
Feature nameVersion as maintenance-/service switch (EF006986)
Feature valueYes
Feature nameVersion as safety switch (EF006985)
Feature valueNo
Feature nameVersion as emergency stop installation (EF006959)
Feature valueNo
Feature nameVersion as reversing switch (EF009408)
Feature valueNo
Feature nameNumber of switches (EF005586)
Feature value1
Feature nameMax. rated operation voltage Ue AC (EF007355)
Feature value1000 V
Feature nameRated operating voltage (EF001435)
Feature value1000 V
Feature nameRated permanent current Iu (EF001389)
Feature value200 A
Feature nameRated permanent current at AC-23, 400 V (EF011777)
Feature value200 A
Feature nameRated permanent current at AC-21, 400 V (EF009165)
Feature value200 A
Feature nameRated short-time withstand current lcw (EF007050)
Feature value8 kA
Feature nameRated operation power at AC-23, 400 V (EF007027)
Feature value110 kW
Feature nameSwitching power at 400 V (EF009166)
Feature value110 kW
Feature nameNumber of poles (EF001391)
Feature value3
Feature nameNumber of auxiliary contacts as normally closed contact (EF001377)
Feature value0
Feature nameNumber of auxiliary contacts as normally open contact (EF001376)
Feature value0
Feature nameNumber of auxiliary contacts as change-over contact (EF003531)
Feature value0
Feature nameMotor drive optional (EF007386)
Feature valueNo
Feature nameMotor drive integrated (EF006697)
Feature valueNo
Feature nameVoltage release optional (EF007491)
Feature valueNo
Feature nameDevice construction (EF008240)
Feature valueComplete device in housing
Feature nameSuitable for floor mounting (EF025108)
Feature valueNo
Feature nameSuitable for front mounting 4-hole (EF007247)
Feature valueNo
Feature nameSuitable for front mounting centre (EF007248)
Feature valueNo
Feature nameSuitable for distribution board installation (EF007262)
Feature valueYes
Feature nameColour control element (EF007167)
Feature valueBlack
Feature nameInterlockable (EF006281)
Feature valueNo
Feature nameHousing colour (EF000136)
Feature valueGrey
Feature nameType of electrical connection of main circuit (EF006819)
Feature valueBolt connection
Feature nameDegree of protection (IP), front side (EF003118)
Feature valueIP00
Feature nameDegree of protection (NEMA) (EF011959)
Feature valueOther
Feature nameWidth (EF000008)
Feature value145.5 mm
Feature nameHeight (EF000040)
Feature value150 mm
Feature nameDepth (EF000049)
Feature value82.5 mm
