ABBContactors and overload relays1SBN010042R1222 ABB CA5-22NRT Auxiliary Contact
ABB 1SBN010042R1222 1SBN010042R1222 - Image 1

Images are for illustrative purposes only. Please refer to data sheet for details.

1SBN010042R1222 ABB CA5-22NRT Auxiliary Contact

Reference: 1SBN010042R1222

Manufacturer: ABB

Description:

CA5-22NRT Auxiliary Contact
CA5-22NRT Auxiliary Contact Block

Categories:

  • Low-voltage industrial components > Auxiliary contact block
  • ABB > Contactors and overload relays

Brand new product in its original packaging covered by the warranties and certifications provided by ABB

  • More Info
  • ETIM
  • Reviews
Guarantee, repair and return.

Total: 49,54 €

Unit Price: 24,77 €

This price is per unit and is the net value (not including taxes if applicable).

Calculate price by quantity

QuantityPrice

Standard lead time: 25 days.

  • These delivery times are an estimate any may vary when the item order has been processed.

LAST VIEWED

MORE INFO

Ordering
Minimum Order Quantity2 piece
Customs Tariff Number85389099
Popular Downloads
Data Sheet, Technical Information1SBC100122C0202_Ch04
Instructions and Manuals1SBC101011M5501
CAD Dimensional Drawing2CDC001079B0201
Dimensions
Product Net Width43 mm
Product Net Depth / Length39 mm
Product Net Height47 mm
Product Net Weight0.06 kg
Technical
Number of Auxiliary Contacts NO2
Number of Auxiliary Contacts NC2
Number of Poles4P
Rated Operational VoltageAuxiliary Circuit 690 V
Rated Frequency (f)Auxiliary Circuit 50 / 60 Hz
Rated Operational Current AC-15 (Ie)(500 V) 2 A
(690 V) 2 A
(24 / 127 V) 6 A
(220 / 240 V) 4 A
(380 / 400 V) 3 A
Rated Operational Current DC-13 (Ie)(24 V) 6 A / 144 W
(48 V) 2.8 A / 134 W
(72 V) 1 A / 72 W
(110 V) 0.55 A / 60 W
(125 V) 0.55 A / 69 W
(220 V) 0.30 A / 66 W
(250 V) 0.3 / 75 W
Rated Short-time Withstand Current Low Voltage (Icw)for 0.1 s 140 A
for 1 s 100 A
Rated Insulation Voltage (Ui)acc. to IEC 60947-5-1 690 V
acc. to UL/CSA 600 V
Degree of Protectionacc. to IEC 60529, IEC 60947-1, EN 60529 Auxiliary Terminals IP10
Terminal TypeRing-Tongue Terminals
Suitable ForN22E
N31E
N40E
NL22E
NL31E
NL40E
TNL22E
TNL31E
TNL40E
Product NameAuxiliary Contact Block
Material Compliance
Conflict Minerals Reporting Template (CMRT)9AKK108467A5658
REACH Declaration2CMT2021-006202
RoHS Declaration2CMT2021-006277
RoHS InformationFollowing EU Directive 2011/65/EU and Amendment 2015/863 July 22, 2019
Toxic Substances Control Act - TSCA2CMT2023-006525
WEEE B2C / B2BBusiness To Business
WEEE Category5. Small Equipment (No External Dimension More Than 50 cm)
Certificates and Declarations
CB CertificateCB_SE_62119A1
CCC CertificateCCC_2015010304800518
CQC CertificateCQC2015010304800518
CQC2004010305133985
Declaration of Conformity - CCC2020980304001627
2020980305001185
Declaration of Conformity - CE1SBD250809U1000
Declaration of Conformity - UKCA1SBD250826U1000
EAC CertificateEAC_RU C-FR ME77 B03391
GOST CertificateGOST_POCCFRME77B07174
RINA CertificateRINA_ELE172319XG001
Container Information
Package Level 1 Units2 piece
Package Level 1 Width65 mm
Package Level 1 Depth / Length129.5 mm
Package Level 1 Height43 mm
Package Level 1 Gross Weight0.12 kg
Package Level 1 EAN3471522364654
External Classifications and Standards
Object Classification CodeK
ETIM 7EC000041 - Auxiliary contact block
ETIM 8EC000041 - Auxiliary contact block
ETIM 9EC000041 - Auxiliary contact block
eClassV11.0 : 27371302
UNSPSC39121522
IDEA Granular Category Code (IGCC)4743 >> Auxiliary contact block

ETIM for 1SBN010042R1222 Low-voltage industrial controls and switchgear (EC000041)

Feature nameNumber of contacts as change-over contact (EF008257)
Feature value0
Feature nameNumber of contacts as normally open contact (EF008256)
Feature value2
Feature nameNumber of contacts as normally closed contact (EF008255)
Feature value2
Feature nameNumber of fault-signal switches (EF007613)
Feature value0
Feature nameRated operation current Ie at AC-15, 230 V (EF001385)
Feature value4 A
Feature nameType of electric connection (EF003961)
Feature valueOther
Feature nameModel (EF000010)
Feature valueClip-on
Feature nameMounting method (EF000003)
Feature valueFront fastening
Feature nameLamp holder (EF000048)
Feature valueNone
