TC4MHR048-E
681090
TC4MHR048E
OMRON
1
High resolution telecentric lens for 1.2" detectors, magnification 0.369 x-mount M42X1 FD=16
Mit hoher Auflösung telezentrische Objektiv für 1,2" - Detektoren, Vergrößerung 0.369 x, M42x1-mount -, Flansch-Abstand 16 mm
Vision Systems > Spezielle Vision
Neues Produkt in der Originalverpackung mit allen Garantien und Zertifizierungen von OMRON
Danke für Ihr Interesse an unseren Produkten, wir hoffen die Lieferzeit ist ok.
Während der Bestellung können Sie den für Sie bestmöglichen Versand wählen: Express 24h, Standard 48h/72h, etc.
Die F3SJ-E-Familie ist ein Sicherheitslichtgitter Typ 4 mit einer optischen Auflösung von 25 mm. Es ermöglicht eine Schutzfeldbreite von bis zu 7 m und eine Schutzfeldhöhe von bis zu 1105 mm ohne Totzone.
Application | Detection capability | Beam gap | Operating range | Protective height (mm) | Order code |
|---|---|---|---|---|---|
Hand protection | Dia. 25 mm | 20 mm | 0.2 to 7 m | 185 to 1,105 | F3SJ-E____P25 |
Note:F3SJ-E uses a 3 m prewired discrete cable.
Number of beams | Protective height (mm) | Order code |
|---|---|---|
8 | 185 | F3SJ-E0185P25 |
10 | 225 | F3SJ-E0225P25 |
14 | 305 | F3SJ-E0305P25 |
18 | 385 | F3SJ-E0385P25 |
22 | 465 | F3SJ-E0465P25 |
26 | 545 | F3SJ-E0545P25 |
30 | 625 | F3SJ-E0625P25 |
34 | 705 | F3SJ-E0705P25 |
38 | 785 | F3SJ-E0785P25 |
42 | 865 | F3SJ-E0865P25 |
46 | 945 | F3SJ-E0945P25 |
50 | 1,025 | F3SJ-E1025P25 |
54 | 1,105 | F3SJ-E1105P25 |
Appearance | Specifications | Application | Remarks | Order code |
|---|---|---|---|---|
Top/bottom bracket | Top/bottom bracket for F3SJ-E/B | 2 for an emitter, 2 for a receiver, total of 4 per set | F39-LJB1 | |
Intermediate bracket | In combination use with top/bottom bracket Can be used as free-location bracket. | 1 set with 2 pieces | F39-LJB2 | |
Quick mount bracket | Quick mount bracket for F3SJ-E/B Supports M6 slide nut for aluminum frame. | 1 set with 2 pieces | F39-LJB3-M6 | |
| Quick mount bracket for F3SJ-E/B Supports M8 slide nut for aluminum frame. | F39-LJB3-M8 | |||
| Quick mount M6 bracket Quick mount M8 bracket | Bracket to mount an intermediate bracket to the aluminum frame | Hexagon socket head cap screws | F39-LJB3-M6K | |
Hexagon socket head cap screws | F39-LJB3-M8K | |||
Compatible mounting bracket | Mounting bracket used when replacing existing area sensors | 2 for an emitter, 2 for a receiver, total of 4 per set | F39-LJB4 | |
Contact mount bracket | Bracket to closely contact the back side of the sensor. | 2 for an emitter, 2 for a receiver, total of 4 per set | F39-LJB5 |
Appearance | Output | Order code |
|---|---|---|
Laser pointer for F3SJ | F39-PTJ |
Model | F3SJ-E____P25 | |
|---|---|---|
Sensor type | Type 4 safety light curtain | |
Setting tool connection | Parameter settings: Not available | |
Safety category | Safety purpose of category 4, 3, 2, 1, or B | |
Detection capability | Opaque objects 25 mm in diameter | |
Beam gap (P) | 20 mm | |
Number of beams (n) | 8 to 54 | |
Protective height (PH) | 185 to 1,105 mm | |
Lens diameter | Diameter 5 mm | |
Operating range | 0.2 to 7 m | |
Response time (under stable light incident condition) | ON to OFF | 15 ms max. |
OFF to ON | 70 ms max. | |
Startup waiting time | 2 s max. | |
Power supply voltage (Vs) | SELV/PELV 24 VDC±20% (ripple p-p 10% max.) | |
Consumption current (no load) | Emitter: Up to 22 beams: 41 mA max., 26 to 42 beams: 57 mA max., 46 to 54 beams: 63 mA max. Receiver: Up to 22 beams: 42 mA max., 26 to 42 beams: 47 mA max., 46 to 54 beams: 51 mA max. | |
Light source (emitted wavelength) | Infrared LED (870 nm) | |
Effective aperture angle (EAA) | Based on IEC 61496-2. Within ±2.5° for both emitter and receiver when the detection distance is 3 m or over | |
Safety outputs (OSSD) | Two PNP transistor outputs, load current 200 mA max., residual voltage 2 V max. (except for voltage drop due to cable extension), Leakage current 1 mA max., load inductance 2.2 H max. | |
Output operation mode | Safety output: On when receiving light | |
Input voltage | ON voltage: Vs-3 V to Vs, OFF voltage: 0 V to 1/2 Vs or open | |
Mutual interference prevention function | Mutual interference prevention algorithm prevents interference in up to 3 sets. | |
Test function | Self test (at power-ON and at power distribution) External test (emission stop function by test input) | |
Protection circuit | Output short-circuit protection, and power supply reverse polarity protection | |
Ambient temperature | Operating: -10 to 55°C (non-freezing), Storage: -25 to 70°C | |
Ambient humidity | Operating: 35% to 85% (no condensation), Storage: 35% to 95% RH | |
Operating ambient light intensity | Incandescent lamp: 3,000 lx max., Sunlight: 10,000 lx max. | |
Insulation resistance | 20 MΩ min. (at 500 VDC) | |
Dielectric strength | 1,000 VAC 50/60 Hz, 1 min | |
Degree of protection | IP65 (IEC 60529) | |
Vibration resistance | Malfunction: 10 to 55 Hz, Multiple amplitude of 0.7 mm, 20 sweeps in X, Y, and Z directions | |
Shock resistance | Malfunction: 100 m/s2, 1,000 times each in X, Y, and Z directions | |
Pollution degree | Pollution degree 3 (IEC 60664-1) | |
Power cable | Connection method: Pull-out type, cable length 3 m Number of wires: Emitter: 5 wires, receiver: 6 wires Cable diameter: Dia. 6 mm Allowable bending radius: R5 mm | |
Extension cable | 30 m max. | |
Material | Case: Aluminum Cap: ABS resin, PBT Optical cover: PMMA resin (acrylic) Cable: Oil resistant PVC | |
Weight (packed state) | Weight (g) = (protective height) × 2.6 + 800 | |
Accessories | Test rod, Instruction Manual, User's Manual (CD-ROM) | |
Applicable standards | IEC 61496-1, EN 61496-1 UL 61496-1, Type 4 ESPE (Electro-Sensitive Protective Equipment) IEC 61496-2, CLC/TS 61496-2, UL 61496-2, Type 4 AOPD (Active Opto-electronic Protective Devices) IEC 61508-1 to -3, EN 61508-1 to -3 SIL3 IEC 13849-1: 2006, EN ISO 13849-1: 2008 (PLe, Cat.4) UL 508, UL 1998, CAN/CSA C22.2 No.14, CAN/CSA C22.2 No.0.8 | |
1.Protective height (mm) = Total sensor length
2.Combining F39-LJB2 and F39-LJB3-M6K makes F39-LJB3-M6.
3.Combining F39-LJB2 and F39-LJB3-M8K makes F39-LJB3-M8.
4.Do not use the support software and setting console for F3SJ-A. Operation cannot be guaranteed.
5.Use of the spatter protection cover causes a 10% maximum sensing distance attenuation.
6.The load inductance is the maximum value when the safety output frequently repeats ON and OFF. When you use the safety output at 4 Hz or less, the usable load inductance becomes larger.
7.These values must be taken into consideration when connecting elements including a capacitive load such as capacitor.
8.The Vs indicates a voltage value in your environment.
9.To extend a cable of the F3SJ-E, refer to the user's manual (SCHG-733/732).
10.Mounting brackets are sold separately.
