PCU2066R5
ELDON
1
Verfügbar Schiff am heute
Verkabelung Rahmen 200x600x600 PCU2066R5
ZOCALO PCU-200x600x600 R5 Socket-für Sammelschienen und Verkabelung 200x600x600
This frame creates additional space in the bottom and can be segregated from the enclosure. It has a universal hole pattern for mounting accessories easily.
Elektroverteiler-Systeme (inkl. Installationsverteiler) > Zubehör/Ersatzteile für Kleinverteiler
Stromverteilung
* Neues Produkt in der Originalverpackung mit allen Garantien und Zertifizierungen von ELDON
Danke für Ihr Interesse an unseren Produkten, wir hoffen die Lieferzeit ist ok.
Während der Bestellung können Sie den für Sie bestmöglichen Versand wählen: Express 24h, Standard 48h/72h, etc.
Beschreibung: | For fixing and routing of cables or mounting of busbar. Identical hole pattern to the enclosure's frame makes all relevant accessories (e.g. CLPF, CLPK, etc) possible to mount. Fixed to the base of the enclosure by M12 screws (provided). |
Material: | Frame in 1.75 mm steel plate, panels in 1.35 mm steel plate. |
Oberfläche: | RAL 7035 structured powder coating. |
Schutzart: | IP 41 TYPE 1. |
Montagemöglichkeiten: | Add side panels PCUP for closing the sides. |
Verpackungseinheit: | 1 piece with front and back cover plates with mounting accessories. |
Feature: | Bottom extension frame for mild steel combinable floor standing enclosures. |
Advantage: | The frame creates additional space at the bottom of the enclosure with integrated hole patterns and allows segregation if required. |
Benefit: | The frame can be segregated from the enclosure which creates extra space for hazardous components, for example main busbars. Standard accessories can be mounted within the frame thanks to the universal hole pattern allowing accessories to be easily mounted, e.g. busbar supports. |
Comment: | Side panels PCUP, are required at the beginning and end of the individual or bayed bottom extension frames. |
Titel: | Größe: | Typ: |
---|---|---|
PCU2066R5 PCU2066R5 DE_PCU2046R5.pdf | 138 Kbytes | |
Gesamtkatalog herunterladen |
