Produkt:MTZ18-4VM DANFOSS REFRIGERATION Hubkolbe...

Die Bilder sind nur orientativ. Bitte prüfen Sie das Artikelstammdatenblatt.
Artikel-Nr.: 088L0444
Hersteller: DANFOSS HEATING
Beschreibung:
Kategorien:
Neues Produkt in der Originalverpackung mit allen Garantien und Zertifizierungen von DANFOSS HEATING
ZULETZT ANGESEHEN
Temperatureinstellbereich [°C]: -10 - 10, Displaytyp: KEIN DISPLAY
| Bruttogewicht | 0.3 Kilogram |
| Gewicht netto | 0.18 Kilogram |
| Volume | 0.761 Liter |
| EAN | 5703466130346 |
| Art | ECtemp 330er-Reihe |
| Produktgruppe | Thermostate |
| Product Line | 21 |
| Bruttogewicht | 0.3 Kilogram |
| Gewicht netto | 0.18 Kilogram |
| Volume | 0.761 Liter |
| EAN | 5703466130346 |
| Art | ECtemp 330er-Reihe |
| Produktgruppe | Thermostate |
| Product Line | 21 |
| Anwendung | Pipe / tank frost protection Asphalt ice and snow melting Cold store Ground ice and snow melting Roof frost protection Sport fields Vineyard frost protection |
| Anzeigeart | LED |
| Breite [mm] | 36 mm |
| Breite Paket [mm] | 95 mm |
| CE evaluated | Yes |
| China RoHS compliance | Yes |
| Contains batteries | No |
| Definitionspunkt Fühler [Ohm/°C] | 15kΩ / 25°C |
| Description | ECtemp 330 -10<>+10° |
| DIN-Montage | Ja |
| Displaytyp | KEIN DISPLAY |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Element-Schutzklasse | 20 |
| EU RoHS compliance | Yes |
| Farbe | Weiß RAL 9010 |
| Fühler, Typ | Ader |
| Garantie [Jahr] | 2 |
| Hysterese (+/-) | 0.2 |
| Höhe [mm] | 86 mm |
| Höhe Paket [mm] | 85 mm |
| In scope of WEEE | Yes |
| Induktive Last | cos φ= 0.3 max 1A |
| Kabelschuhgröße max. [mm²] | 2 x 2.5 |
| Kugeldruckprüfungstemperatur [°C] | 75 °C |
| Lagertemperatur [max.] [°C] | 65 °C |
| Lagertemperatur [min.] [°C] | -20 °C |
| Leistungsaufnahme im Standby-Betrieb [W] [max.] | 0.25 W |
| Ohmsche Last maximal [A] | 16 A |
| Produktbeschreibung | ECtemp 330 |
| REACH-Kandidatenliste Stoffe | No |
| Regelungsart | Hysterese |
| Relaisschalter | einpolig |
| Skaleneinstellung | -10 +10ºC |
| Temperatureinstellbereich [°C] [max.] | 10 °C |
| Temperatureinstellbereich [°C] [min.] | -10 °C |
| Tiefe [mm] | 58 mm |
| Tiefe Paket [mm] | 140 mm |
| UL evaluated | Out of scope |
| Umgebungstemperatur [°C] [max.] | 50 °C |
| Umgebungstemperatur [°C] [min.] | -10 °C |
| UNSPSC-CODE | 41112209 |
| Verschmutzungsgrad | 2 |
| Versorgungsspannung [V] [AC] | 230 V |
| Versorgungsspannung [V] AC [max.] | 240 V |
| Versorgungsspannung [V] AC [min.] | 220 V |
| Warranty type | 2-year product warranty |
| Zerifizierungsunternehmen | NEMKO |
| Zulassung | CE |
| Zweipoliger Schalter | Nein |
| Anwendung | Pipe / tank frost protection Asphalt ice and snow melting Cold store Ground ice and snow melting Roof frost protection Sport fields Vineyard frost protection |
| Anzeigeart | LED |
| Breite [mm] | 36 mm |
| Breite Paket [mm] | 95 mm |
| CE evaluated | Yes |
| China RoHS compliance | Yes |
| Contains batteries | No |
| Definitionspunkt Fühler [Ohm/°C] | 15kΩ / 25°C |
| Description | ECtemp 330 -10<>+10° |
| DIN-Montage | Ja |
| Displaytyp | KEIN DISPLAY |
| EEE category | 5 small equipment (any external dimension < 50 cm) |
| Element-Schutzklasse | 20 |
| EU RoHS compliance | Yes |
| Farbe | Weiß RAL 9010 |
| Fühler, Typ | Ader |
| Garantie [Jahr] | 2 |
| Hysterese (+/-) | 0.2 |
| Höhe [mm] | 86 mm |
| Höhe Paket [mm] | 85 mm |
| In scope of WEEE | Yes |
| Induktive Last | cos φ= 0.3 max 1A |
| Kabelschuhgröße max. [mm²] | 2 x 2.5 |
| Kugeldruckprüfungstemperatur [°C] | 75 °C |
| Lagertemperatur [max.] [°C] | 65 °C |
| Lagertemperatur [min.] [°C] | -20 °C |
| Leistungsaufnahme im Standby-Betrieb [W] [max.] | 0.25 W |
| Ohmsche Last maximal [A] | 16 A |
| Produktbeschreibung | ECtemp 330 |
| REACH-Kandidatenliste Stoffe | No |
| Regelungsart | Hysterese |
| Relaisschalter | einpolig |
| Skaleneinstellung | -10 +10ºC |
| Temperatureinstellbereich [°C] [max.] | 10 °C |
| Temperatureinstellbereich [°C] [min.] | -10 °C |
| Tiefe [mm] | 58 mm |
| Tiefe Paket [mm] | 140 mm |
| UL evaluated | Out of scope |
| Umgebungstemperatur [°C] [max.] | 50 °C |
| Umgebungstemperatur [°C] [min.] | -10 °C |
| UNSPSC-CODE | 41112209 |
| Verschmutzungsgrad | 2 |
| Versorgungsspannung [V] [AC] | 230 V |
| Versorgungsspannung [V] AC [max.] | 240 V |
| Versorgungsspannung [V] AC [min.] | 220 V |
| Warranty type | 2-year product warranty |
| Zerifizierungsunternehmen | NEMKO |
| Zulassung | CE |
| Zweipoliger Schalter | Nein |
