KBH1S02
LOVATO ELECTRIC
1
Final de carrera Plástico De palanca con rodillo cerámico Acción Acción Brusca 2 NC
INTERRUPTOR DE LÍMITE, SERIE K, PALANCA DE VARILLA DE CERÁMICA, 1 ENTRADA DE CABLE INFERIOR. DIMENSIONES A EN 50047, CUERPO DE PLÁSTICO, CONTACTOS 2NC SNAP ACTION. VARILLA DE CERÁMICA
Finales de Carrera Micros Pedales - LOVATO ELECTRIC
* Producto nuevo en su embalaje original con todas las garantías y certificaciones de LOVATO ELECTRIC
Gracias por su interés en nuestros productos, esperamos que el plazo indicado sea conveniente para usted.
Durante la tramitación del pedido podrá seleccionar el tipo de envío que mejor se adapte a sus necesidades: Aéreo Express 24Hrs, Terrestre Standard 48/72Hrs, etc.
Código de pedido | KBH1S02 |
Peso [g] | 120 |
Unidades de embalaje | 1 |
Cantidad de pedido multi-embalaje | 5 |
Dimensiones de embalaje [mm] | 150X060X036 |
Volumen [cm³] | 324 |
Código de barras [EAN13] | 8013975114827 |
Código HS | 85365080 |
Product designation | Ceramic rod lever | |||
Product type designation | KBH | |||
General characteristics | ||||
Material | ||||
Housing | Self-extinguishing double-insulation polymer thermoplastic | |||
Rod | Ceramic | |||
Contact characteristics | ||||
Type of contact | 2NC Snap action | |||
Thermal current Ith | A | 10 | ||
IEC/EN 60947-5-1 designation | A600 Q300 | |||
Rated insulation voltage Ui | V | 690 | ||
Rated impulse withstand voltage Uimp | kV | 6 | ||
Insulation class | II | |||
Short-circuit protection with fuse | Class/A | 10 gG/SC QUICK FUSE | ||
Switching speed | ||||
min | m/s | 0.5 | ||
max | m/s | 1.5 | ||
IEC Conventional free air thermal current Ith | A | 10 | ||
Resistance per pole (average value) | mΩ | <10 | ||
Mechanical features | ||||
Operating head fixing | Locking bayonet insert | |||
Operating torque | ||||
Ncm | 3 | |||
ozin | 4.25 | |||
Tightening torque (Max) | ||||
Switch fixing | ||||
Nm | 2.5 | |||
lbin | 22.1 | |||
Contact terminals | ||||
Nm | 0.8 | |||
lbin | 7 | |||
Body lid screw fixing | ||||
Nm | 0.8 | |||
lbin | 7 | |||
Conductor section | ||||
AWG/Kcmil | ||||
min | 16 | |||
max | 14 | |||
IEC | ||||
min | mm² | 1or 2 | ||
max | mm² | 2.5 | ||
Cable connection | Self-releasing screw terminal | |||
Cable entry | M20 on the bottom | |||
Operations | ||||
Mechanical life | cycles | <10000000 | ||
Mechanical operation | cycles/h | 3600 | ||
Ambient conditions | ||||
Temperature | ||||
Operating temperature | ||||
min | °C | -25 | ||
max | °C | +70 | ||
Storage temperature | ||||
min | °C | -40 | ||
max | °C | +70 | ||
Resistance & Protection | ||||
IP degree | ||||
Terminals | IP20 | |||
Body housing | IP65 | |||
Pollution degree | 3 | |||
ETIM classification | ||||
ETIM 8.0 | EC000030 - End switch |
Título: | Tamaño: | Tipo: |
---|---|---|
KBH1S02 KBH1S02 09-Finales-de-carrera-microinterruptores-e-interruptores-de-pedal-09-enero-2018_ES.pdf | 2 Mbytes |
