LDB-300L
MEANWELL
1
Available Ship on today
DC-DC Buck-Boost LED Driver (CC), Input 9-36VDC, Output 40VDC / 0.3A, Built-in PWM and Remote ON/OFF, Pin Style Connections
LED DRIVERS > LDB
* Brand new product in its original packaging covered by the warranties and certifications provided by MEANWELL
Thank you for your interest in our products; we hope the delivery time indicated is to your convenience.
While the order is being processed you can select the type of shipment that best suits your needs: 24-hour air express, standard 48-72 hour land, etc.
Name | LDB-300L |
---|---|
Long Description | LED driver input and continuous output in a steady stream. Specially designed for applications of solar street lights powered from battery. Format in box with connection pins.IP67. Input rangeNine-36Vcc. Output in constant current300mA. Range of output voltage with current mode constantTwoto 40Vccaccording to demand load. Regulator Buck-Boost (Vout >< Vin). Power:12W. Efficiency typical:89% (12vdc)and90% (24vdc). Regulation0% to 100% of the output intensity with a PWM signal. Consumption without load 1mA in power-off mode. Operating temperature range of caseTcfrom-40ºCup+71ºC. Dimensions (Length x Width x Height):31,8 x 20,3 x 12.2 mm. 3 years of warranty. Manufacturer: MEAN WELL. The series LDB-L with current regulators intended to power the leds from a battery or dc voltage. These teams can be dimmed with a PWM signal. This series are reducing and lifts voltage (Buck-Boost, Vout >< Vin), which will reduce or increase the input voltage to an output voltage lower or higher by keeping the output current constant.The output must not be connected to the input of the same unit or output from other sources. |
Country of Origin | Taiwan |
Manufacturer | MEAN WELL |
Product type | LED Driver |
Format | Box |
Subformato | Encapsulated |
Applications | Lighting, Solar |
Series | LDB-L |
State | Recommended Model |
Warranty (Years) | 3,00 |
Height (mm) | 12.20 |
Width (mm) | 20.30 |
Long/Background | 31.80 |
Range DC Input | 9, 9,2, 10, 10,5, 10,8, 12, 13,5, 14, 14,4, 15, 16,2, 16,5, 16,8, 18, 19, 22,5, 24, 25,2, 28, 28,8, 30, 31,2, 32, 32,4, 33,6, 35, 36 |
Input connector | Pin |
Output current mA | Three hundred |
Power (W) | 12,00 |
Peak Power (W) | Twelve |
Dimming | Signal PWM 10V |
Output connector | Pin |
Approvals | EC |
